LMWEKITU

LiftMaster Wireless Edge Kit Monitored

Meets 2016 UL 325 requirements
low-energy Bluetooth® transmission up to 130 ft. range
Integrated Diagnostics with Gate Operator Speed Installation
Protects up to 8 entrapment points
Receiver accepts up to 4 transmitters
Transmitter accepts up to 2 wired resistive edges

.......more details

Installation manual Manuel d'installation Instruction manual Manuel d'instructions Product Guide Guide de produit

LMWETXU

LiftMaster Wireless Edge Transmitter Monitored

Connects to wireless edge receiver using low-energy Bluetooth transmission
Sensing distance up to 130 ft
Transmitter accepts up to 2 wired resistive edges
Battery life 2 years
NEMA 4X rated
Compatible with LMWEKITU Wireless Edge Kit and L50 and S50 Monitored Resistive Edges

.......more details

Installation manual Manuel d'installation Product Guide Guide de produit

OES-5104

LiftMaster 2" x 2" PVC Channel 16ft

Connects the door to the edge kit. 16' total (sectional doors only).

CPS-UN4G

LiftMaster Commercial Protector System Thru-Beam Eyes NEMA4 Black

Waterproof photoeyes.
Monitored Thru Beam Photocell
For direct connect on HCT

50-HERK-RC2

Hercules Infrared Programming Remote Red (50-HERK-RC2)

Conveniently choose from 8 different preset comfort functions to adjust detection fields mounting heights relay hold interval cross traffic optimization direction recognition people/vehicle separation slow motion detection turn on/off filter functions open the door manually and much more
Bidirectional
Fine-tune the motion detector from the ground without guessing if all the settings have been received by the sensor

50-HERK2

Hercules Microwave Motion Detector for Industrial Doors

Opens after sensing an object.
Can be set up to detect vehicles separately from people and bring the two signals to two different outputs
Or use the two outputs to differentiate between forward and backward movements
Detection fields are adjustable - manually or with a remote control (sold separately)
Can be mounted between 8.2' up to 23' with max range of 80'
Reference height of 23' and angle of 45 degrees

.......more details

503267

PEEK Vehicle Loop Detector 24V with Harness Nema 1 ** Discontinued

Enclosed requires separate 24VAC power.
Wiring harness with plug for detector included.
OPEN only (all LiftMaster operators) or SAFETY/HOLD OPEN only (operators with type B2 T TS or T1 control wiring) when vehicle passes over loop wire
Requires a loop of wire embedded in the ground to connect to the detector.
Requires 2-wire output connection to door operator and 24VAC power
Also known as: G50625S24

.......more details

LMTBU

LiftMaster Monitored Through Beam Photo Eye Nema 4X ** To exent of inventory

Meets 2016 UL 325 requirements
Long Range powerful beam provides reliable performance.
Sensing distance up to 90 ft.
Anti-Fogging Lens
NEMA 4X rated
Wireless network mode eliminates the need to wire between operators in dual-gate applications.

.......more details

CPS3-N4

LiftMaster Option Card with CPS-UN4 Eyes for applications requiring 2 sets of photocells

For applications requiring two sets of photoeyes in a damp location
Range up to 45ft water dust and corrosion proof eyes (Nema 4x rating)
Works with Logic 3 4 5 Commercial Operators
Includes Durable steel brackets - floor or track mounting
Kit Inludes one set of CPS-UN4 and one CPS3 card ( CPSIII )

CPS3CARD

LiftMaster Option Card Only (41K0811)

Works with all commercial Logic versions L2 L3 L4 L5
Use with CPS-U to add a second set of eyes to the operator
Allows activation of Timer-To-Close without CPS-U
Simply plugs into Logic board
Cut resistors on JU1 & R16 to activate timer feature
Same as 041K0811

.......more details

LD7LP

LiftMaster 10-30VAC/DC Low Power Loop Detector (50-DSP7LP)

10-30 VAC/DC low power fail-safe loop detector
<2mA stand-by current draw
Compact design - ideal for linear actuator control boxes
Automatic sensitivity and frequency adjustments
Ideal for solar or battery powered gate applications

50800P

LiftMaster Treadle Protection Plate **discontinued

50800

LiftMaster RBMA Electric Treadle Nema 4/12 5ft long

Five feet long.
OPEN only (all LiftMaster operators) or SAFETY only (LiftMaster operators with type B2 C2 L2 T T1 or TS control wiring) after vehicle passes over treadle.
The weight of the vehicle compresses an electric switch which sends an open signal to the door.
Requires a 2-wire connection to the operator but does not require power to function

LC-36A

LiftMaster Light Curtain **discontinued

Must be used with a primary entrapment device and be installed along the vertical plane of the door.
Color-coded transmitter and receiver for easy identification.
Provides 36 in. of effective height coverage to increase the area of protection.
Multiple sets of LC-36A curtains can be mounted on a door providing coverage flexibility.
Maximum door width of 33 ft. ensures coverage for most commercial doors.
Eight (8) LEDs per side and 22 cross-beams produce an invisible curtain of infrared light for maximum detection capability.

.......more details

Installation Manual Manuel d'Installation Sell Sheet Connecting the lc-36A to a Non-LiftMaster Opener

CPS-MEI

LiftMaster Electric Edge Card **to extent of inventory

The CPS-MEI is an interface for a monitored 2-wire edge that can be used in place of photo eyes and meets the monitored requirement of UL325-2010
Same as Miller Edge SM-102

AELD

LiftMaster Elite Plug-In Loop Detector

For use with Omni Control board available on the Chamberlain commercial line.

Installation Manual

CPS-RN4

LiftMaster Retro-Reflective Commercial Protector System with Nema 4 Enclosure ** DISCONTINUED

Utilizes a sending/receiving retro-reflective photo-eye and a specially designed polarized reflector that increases obstruction detection reliability
Polarized photo-eye design for a safe retro-reflective photo-eye system
Designed as a normal open circuit but not a self-monitoring system (does not incorporate industrial code technology)
Range up to 30 ft - indoor use only
24VAC operation
Color: Yellow

.......more details

Installation Manual
