Home Commercial Door Operators
OCS-PANEL

GDI Panel Buttons Open/Close/Stop N1/ N4 G3253

  • Power LED
MH5011U-LH

LiftMaster 1/2 HP 120 Volt Medium Duty Jackshaft Operator

  • 1/2 HP 120 volt 1 phase medium-duty hoist operator Logic board with integral 315 MHz radio receiver for Open/Close or Open/Stop/Close
  • CPSU commercial photoeyes included ( Nema 4 optional)
  • 4L V-Belt #48 drive chain adjustable friction clutch
  • Emergency disconnect and chain hoist standard
  • Solenoid actuated disc brake
  • Door speed approximately 8" to 12" per second
    • .......more details
Installation ManualManuel d'installationMH Sell SheetMH Shop Drawing
MH5011U-RH

LiftMaster 1/2 HP 120 Volt Medium Duty Jackshaft Operator

  • 1/2 HP 115 volt 1 phase medium-duty hoist operator
  • Logic board with integral 315 MHz radio receiver for Open/Close or Open/Stop/Close
  • CPSU commercial photoeyes included ( Nema 4 optional)
  • 4L V-Belt #48 drive chain adjustable friction clutch
  • Emergency disconnect and chain hoist standard
  • Solenoid actuated disc brake
    • .......more details
Installation ManualManuel d'installationMH Sell SheetMH Shop Drawing
JHDC7S1BE

LiftMaster MAXUM Jackshaft 1/2HP 120/240V 1PH DC Operator 30 Cycles/Hour 700LB long output shaft

  • New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
Auxiliary ModificationDual Auxiliary Trolley ModificationMAXUM Installation ManualMAXUM Manual dinstallationMAXUM Fiche TechniqueMAXUM Data SheetMAXUM Product GuideMAXUM Buying Guide
JHDC12S1BE

LiftMaster MAXUM Jackshaft 3/4HP 120/240V 1PH DC Operator 30 Cycles/Hour 1200LB 3" output shaft

  • New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
Auxiliary ModificationDual Auxiliary Trolley ModificationMAXUM Manual dinstallationMAXUM Installation ManualMAXUM Fiche TechniqueMAXUM Data SheetMAXUM Product GuideMAXUM Buying Guide
LJ8900W

LiftMaster Light Duty Jackshaft Door Op. for Sectional Doors

  • Ideal for smaller/lighter commercial doors with light duty cycle requirements
  • MyQ Technology Built-In Wi-Fi Real-Time Alerts
  • Smooth Start/Stop
  • Optional Accesories 877LM Keypad 827LM MyQ Remote LED light 485LM Battery Back-up 841LM Automatic Door Lock 480LMB Alternate Mounting Kit and LC-36A Light Curtain
  • Compatible remotes; 893MAX 891LM 893LM
Installation manualSell sheetBrochureGuide De Produit
OSH-6113-M-N1-RH

Manaras Opera-SH 3/4HP 120V 1Ph Monitored Board w/N1 Eyes RH

  • An ultra high-end heavy-duty V-belt drive industrial jackshaft operator
  • For use on Standard High and Vertical Lift sectional doors
  • Can also be used on Rolling doors and Grilles
  • Comes with a chain hoist for manual operation and a floor level engaging device
  • Clearence: side room required 16"
  • 25 cycles per day > 100 cycles per day
    • .......more details
Installation ManualSell Sheet
TDC12X1BMC

LiftMaster MAXUM Trolley DC Comm. Op 3/4HP Equivalent 120/240V 1PH 100 Cycles/Hr 1200LB

  • Smooth Start/Stop Operation - DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator.
  • Faster Speed - Average of 12” per second opening on sectional doors.
  • Battery Backup Option - (battery backup kit sold separately DC7AH).
  • Floor-Level Wall Controller - 4-line LCD display gives you access to programming troubleshooting and diagnostics at floor level saving time and money.
  • Wi-Fi® and myQ® - Easily connect to myQ Facility via Wi-Fi for visibility into what is happening at your door and control it from your web browser; no need for additional hubs or accessories. Know what accessories activate the door (remote transmitter keypad etc.)
  • Drive Type 65:1 Gearbox with #50 Chain Output
    • .......more details
TDC_Installation-manualTDC_Manuel-installationData sheetFiche techniqueQuick connect guideGuide de connexion rapideOrdering guide
TDC1222-12

Liftmaster Comm. 12FT Trolley Angle set (10-5812-P x 2) and #41 chain pack (TDC41-12) ***Actual length 179"***

  • Double Angle Rails for doors up to 12'6" high
  • Includes #41 chain pack
JHDC12X1BE

LiftMaster MAXUM Jackshaft 3/4HP 120/240V 1PH DC Operator 100 Cycles/Hour 1200LB

  • DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
MAXUM Sprocket Recommendations
PRO-HB-5011U-LH

Micanan 1/2HP 115V 1P Hoist Op. with Brake N1 Eyes Monitored ECB Left Hand

  • Continuous duty belt drive jackshaft operator with emergency chain hoist
  • Full function Smart 10.0 Logic control board featuring on-board receiver with antenna
  • Nema 1 photoeyes included
  • Solenoid brake included
  • On-Board receiver holds up to 20 transmitters
Installation manualSpecification sheet
PRO-HB-7511U-LH

Micanan 3/4HP 115V 1P Hoist Op. with Brake N1 Eyes Monitored ECB Left Hand

  • Continuous duty belt drive jackshaft operator with emergency chain hoist
  • Full function Smart 10.0 Logic control board featuring on-board receiver with antenna
  • Nema 1 photoeyes included
  • Solenoid brake included
RBH105L5-RH

LiftMaster 1 HP 575 VAC 3 PH Comm. Hoist Op. Logic 5 Right Hand ** To Extent of Inventory

  • H-style operators include a floor level chain hoist to ease manual operation in an emergency or power outage.
  • The operators are typically mounted to the wall when used with larger sectional overhead doors with vertical or high lift and mounted to the wall or the front of the hood when used with rolling doors and grilles.
  • H operators are attached to the door jackshaft to indirectly drive the door.
  • With the addition of the 828LM MyQ technology enables the user to monitor and control their operator and light with their smartphone tablet or computer.
  • Alerts can be received as email or pop-up (push) notifications on a mobile device ensuring the status of your commercial door.
  • Security+ 2.0™ safeguards your facility – with every click a new code is sent to the commercial door operator so the door opens only for you.
    • .......more details
OGH-6214-M-N1-RH

Manaras 1 HP 240V 1Ph Gear Head Operator with Monitored ECB N1 Eyes Right Hand

  • A heavy-duty worm gear industrial operator designed for use on industrial standard high and vertical lift sectional doors or rolling doors and grills.
  • Includes a self-engaging chain hoist for manual operation
  • 25 cycles per hour 80 cycles a day
  • Hoist on right side standard can easily be moved to the left in field
  • Full overload protection
  • BRACKET112 must be used for wall mounting
    • .......more details
OGH-6115-M-N1-RH

Manaras 1-1/2 HP 120V 1Ph Gear Head Operator with Monitored ECB N1 Eyes Right Hand

  • A heavy-duty worm gear industrial operator designed for use on industrial standard high and vertical lift sectional doors or rolling doors and grills.
  • Includes a self-engaging chain hoist for manual operation
  • 25 cycles per hour 80 cycles a day
  • Hoist on right side standard can easily be moved to the left in field
  • Full overload protection
  • BRACKET112 must be used for wall mounting
    • .......more details
PRO-LH-5011U-RH

Micanan 1/2HP 115V 1P Medium-Duty Jackshaft with Brake N1 Eyes Monitored ECB Right Hand

  • Designed for use on commercial sectional doors with high or vertical lift
  • May also be used on small rolling grilles with max. 15 cycles per hour
  • Includes chain hoist
  • Includes solenoid brake
  • On board receiver with antenna
  • On-Board receiver holds up to 20 transmitters
    • .......more details
Installation manualSpecification sheetFiche technique
PRO-HBH-7553U-R

Micanan 3/4HP 575V 3P Heavy-Duty Jackshaft N1 Eyes Monitored ECB Right Hand

  • 3/4 HP575V 3PH Industrial Continuous Duty Jackshaft Operator Ideal for Sectional Doors Rolling Steel
  • Monitored logic board with integral 372Mhz radio receiver that can hold up to 20 transmitters (MK-00647/ MK-00653/ MK-00659) or 200 of the 1 channel hand held transmitters (MK-00660).
  • N-1 Through-beam (MK-00649) photocells included. Other options available.
  • 3-btn O/S/C (02-103) wall control station included
  • Adjustable Friction Clutch 5L320 drive belt
  • #50 Roller chain 18 tooth door sprocket included
    • .......more details
MGH-6235-M-N1-RH

Manaras 1.5 HP 208V 3P Jackshaft Monitored w/N1 Eyes Right Hand

  • A very heavy-duty worm gear industrial operator designed for use on Industrial standard high and vertical lift sectional or rolling doors and grilles.
  • It incorporates a chain hoist for manual operation with a floor level engaging device with electrical cut-out
  • Electrically activated drum-band type solenoid brake
  • Full overload protection
Specification Sheet Drawing Diagram
RBH101L5-RH

LiftMaster 1 HP 115/230 VAC 1 PH Commercial Hoist Operator Logic 5 ** To Extent of Inventory

  • H-style operators include a floor level chain hoist to ease manual operation in an emergency or power outage.
  • The operators are typically mounted to the wall when used with larger sectional overhead doors with vertical or high lift and mounted to the wall or the front of the hood when used with rolling doors and grilles.
  • H operators are attached to the door jackshaft to indirectly drive the door.
  • With the addition of the 828LM MyQ technology enables the user to monitor and control their operator and light with their smartphone tablet or computer.
  • Alerts can be received as email or pop-up (push) notifications on a mobile device ensuring the status of your commercial door.
  • Security+ 2.0™ safeguards your facility – with every click a new code is sent to the commercial door operator so the door opens only for you.
    • .......more details
Installation manualManuel d'installationSell sheet
TDC12S1BMC

LiftMaster MAXUM Trolley DC Comm. Op 3/4HP Equivalent 120/240V 1PH 30 Cycles/Hr 1200LB

  • Smooth Start/Stop Operation - DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator.
  • Faster Speed - Average of 12” per second opening on sectional doors.
  • Battery Backup Option - (battery backup kit sold separately).
  • Floor-Level Wall Controller - 4-line LCD display gives you access to programming troubleshooting and diagnostics at floor level saving time and money.
  • Wi-Fi® and myQ® - Easily connect to myQ Facility via Wi-Fi for visibility into what is happening at your door and control it from your web browser; no need for additional hubs or accessories. Know what accessories activate the door (remote transmitter keypad etc.)
  • Drive Type 65:1 Gearbox with #50 Chain Output
    • .......more details
TDC_Installation-manualTDC_Manuel-installationData sheetFiche techniqueQuick connect guideGuide de connexion rapideOrdering guide
