10TD900INDHH1

BEA 1-Button Digital Transmitter Nema 4 900 MHz

  • Compact transmitter allowing wireless activation of any door control providing greater line-of-sight distance than legacy wireless frequencies.
  • It also provides better penetration of obstacles.
  • IP65
  • Operating temperature: -10 to 55C
  • Controls one 10RD900 receiver
10TD900INDHH2

BEA 2-Button Digital Transmitter Nema 4 900 MHz

  • Compact transmitter allowing wireless activation of any door control providing greater line-of-sight distance than legacy wireless frequencies.
  • It also provides better penetration of obstacles.
  • IP65
  • Operating temperature: -10 to 55C
  • Controls one 10RD900 receiver
BEA-LZR-WIDESCAN

BEA Widescan LZR Motion Sensor Time of Flight

  • Should only be mounted Left Hand or Centre Mount
  • Time-of-flight lazor sensor used for motion safety & presence detection
  • Offers the benefits of activation & safety while reducing installation time.
  • Can detect objects based on direction speed object size & height.
  • The detection field operates independent of ground conditions allowing for superior functionality in harsh environments.
  • Ideal for replacing costly/labor-intensive induction loop & pull-cord solutions
    • .......more details
Mechanical InstallationSell sheet
BEA-10-WBA

BEA Universal Mounting Bracket Arm and Plate

  • Extendable from 15.35" - 23.62"
  • -90 to 90 degree tilt range
  • Self Drilling screws provided
  • Carbon Steel Black Powder Coated
  • Mostly used for WIDESCAN and 10FALCON models
Installation Guide
BEA-10EVOLOOP

BEA EVOLOOP Induction Loop Replacement for Automatic Barrier Gates

  • Evoloop is the alternative to traditional in-ground induction loops used for vehicle detection in parking access and security applications
  • Ideal for Automatic Barrier Gate Operators when installing a tradition in-ground loop is not practical (winter weather or the customer doesn't want to cut new ashalt etc.)
  • Designed with a 140 degree field of view Evoloop allows for up to 3 virtual loops that provide precise detection for control of the barrier.
  • Dimensions: 2" x 6" x 2-5/8"
  • Mounting height between 12" and 27" from the road surface
  • Supply voltage: 12-30VDC +-10% / 12-24V AC +-10%
    • .......more details
BEA-10-FALCN-XL

BEA Falcon-XL Motion Detector Mount under 11'5"

  • Same features as the Falcon detector but made specifically for extra low mounting
  • Mounting height between 6.5' and 11.5'
  • Detection zone: 13'x6.5' at 8 1/5'
  • Allows uni or bi-directional sensing and the unique ability to open a door when traffic is moving away from the sensor.
  • Sensor also has the ability to differentiate between pedstrians and vehicles.
  • Available remote makes it easy to make adjustments to all key parameters of the sensor while at ground level.
    • .......more details
Installation manualManuel d'installationSell sheetCut sheet
BEA-10EAGLE-ARTEK

BEA Eagle Compact Motion Sensor 6'-13' Mounting Height

  • EAGLE ARTEK is a motion sensor for all types of automatic doors. Its slim and compact design ensures discreet integration for your application making it ideal for pedestrian doors.
  • Superior field performance with improved filters that help to reduce false detections.
  • Easy to install and set up with flexible parameters and simple push-button settings. •The detection field can be adjusted without manually adjusting the antenna.
  • Max. detection range: wide: 13’ × 6.5’ narrow : 6.5’ × 7’ (@ 7’ high)
  • Temperature range: -4 – 131 °F (-20 – 55 °C)
  • Cable length: 8’
    • .......more details
Installation manualSpec sheet
IS40P

BEA Presence Sensor

  • Infrared presence sensor for use in industrial applications. The sendor utilizes 40 active infrared spots for reliable detection.
  • Ideal for use on automatic industrial doors vehicle gates/barriers and loading docks.
  • Equipped with 9 pre-programmed pattern configurations for various industrial applications.
  • Various learn time settings allow presence detection to either remain constant or ignore a motionless object after a pre-determined period of time.
  • Mounting height: 8-16'
  • Detection field: 10'x10' at max. mounting height of 16'
    • .......more details
Installation manualSell sheetCut sheet
BEA-10-FALCON

BEA Falcon Motion Detector Mount over 11'5"

  • Motion sensor with microwave activationsolution for industrial indoor and outdoor use.
  • Ideal for automatic industrial doors vehicle gates and detection and loading docks.
  • Sensor also has the ability to differentiate between pedstrians and vehicles
  • Can be set vertically from 0 to 180 degrees
  • Mounting height between 11.5' and 23'
  • 12/24V AC/DC
    • .......more details
Installation manualManuel d'installationSell sheetCut sheet
BEA-REMOTE

BEA Falcon/LZR Programming Remote

  • Makes it easy to set up and make adjustments to all key parameters of the Falcon motion detector while at ground level
Programming instructions
BEA-10-MINI-BRKT

BEA Mini Industrial Bracket Adjustable 6-12 "

  • Adjustable from 6 - 12 inches (up to 4" maybe cut off for shorter applications)
  • 12" x 2.5" Mounting Face
  • Fasteners NOT Included
  • Carbon Steel Black Powder Coated
Installation Guide
BEA-35-1555

BEA 50' of Cable Only for LZR Widescan

  • Optional 50 ft cable for use with the LZR-WIDESCAN
IS40

BEA Industrial Sensor Dual Technology Presence Detection BEA-10IS40

  • Dual technology sensor combining presence and motion detection in industrial applications.
  • Bidirectional unidirectional approach and unidirectional depart microwave detection options. Six modes of detection filtering and 9 uniqueinfrared patterns for highliy flexible presence detection.
  • Up to 7 minimum object targets
  • Adjustable infrared immunity modes to mitigate environmental disturbances (vibrations light and sun)
  • Mounting height: 8'-16'
  • NEMA 4
    • .......more details
Installation manualSell sheetCut sheet
41.8838

BEA LZR-WIDESCAN Replacement Base PVC

  • Replacement base only
35.0245

BEA LZR-WIDESCAN Replacement Cover Only Black

  • Replacement cover for the LZR-WIDESCAN sensor
BEA-10LIGHT-TR

BEA Modular LED Signal Light Segment Red

  • Signal lights for industrial and vehicle flow management applications.
  • LED signal modular lights offer customizable configurations with “build-your-own” lighting elements that share a common base and bracket.
  • These LED signal units are available in red green yellow and an audible alarm cap and can be stacked in a tower configuration with up to six modules.
  • Operating temperature: -40 to 122F
  • Nema 4/IP65
  • Base sold separately
    • .......more details
User GuideDatasheet
IS40-XL

BEA Industrial Sensor Low Mount Dual Technology Presence Detection BEA-10IS40XL

  • Dual technology sensor combining presence and motion detection in industrial applications.
  • Bidirectional unidirectional approach and unidirectional depart microwave detection options. Six modes of detection filtering and 9 uniqueinfrared patterns for highliy flexible presence detection.
  • Up to 7 minimum object targets
  • Adjustable infrared immunity modes to mitigate environmental disturbances (vibrations light and sun)
  • Mounting height: 6.5ft - 11.5ft
  • NEMA 4
    • .......more details
Installation manualSell sheetCut sheet
BEA-10-IXIO-DT1

BEA Presence & Motion Sensor for Automatic Sliding Doors

  • Dual technology motion and presence sensor combining microwave activation and infrared presence detection for the automatic sliding door industry.
  • This solution is highly flexible and user-friendly for sliding doors industrial doors vehicle gate detection and off-door automation.
  • Precise Presence Detection: Two 24-spot high-density infrared safety curtains providing precise presence detection
  • Easily Adjustable: Four visible red alignment spots are projected on the ground to assist in precise IR curtain adjustment
  • Standards Compliant: Fully monitored internally capable of external monitoring
  • Operating temperature: -13 to 131F
    • .......more details
LZR-H100

BEA LZR Gold-Black BLK-02 H100

  • Laser scanner for gate and barrier applications.
  • Provides four laser-based curtains offering a three dimensional detection zone.
  • Detection curtains are highly configurable and can be set up for activation and presence detection in vehicle sensing applications.
  • Effective alternative to induction loops.
  • Max detection range: 32'x32'
  • Cable length: 33'
    • .......more details
LZR-H100 User Guide (EN)LZR-H100 Cut Sheet (EN)LZR-H100 User Guide (FR)LZR-H100 Cut Sheet (FR)
BEA-LZR-S600

BEA LZR-S600 Lazer-Based Time of Flight Sensor

  • The product configuration provides four LASER-based curtains offering a three dimensional presence detection zone.
  • This sensor is ideal for perimeter security protection industrial automation and large industrial door / gate applications that require a wide field of detection
  • The LZR®-S600 is housed in an IP65 rated enclosure and can be installed in outdoor industrial and other harsh environments.
  • Three visible LED spots provide accurate reference points when adjusting the tilt angle.
  • Parameter adjustments can be made with a BEA universal remote control.
  • Maximum detection range of 82 × 82 ft
    • .......more details
