TG-R-PKIT

Miller Edge TrueGuard Monitored Reflective Photo Eye

  • Monitored Reflective Photo eye
  • 30 ft. range
  • 10K pulsed normally closed and normally open outputs
  • Polarized beam and corner cube reflector reject false reflection and increase sunlight immunity
  • Emitter/receiver can be mounted vertically or horizontally
  • Durable mounting bracket/hood and reflector hood provide added protection against debris and serve as weather and sun shields
    • .......more details
MWR22B

Miller Edge 2-Channel Wireless Edge Receiver RF 318 MHz

  • Power source: 12-24 volts AC/DC nominal Nominal 60 mA 140 mA activated
  • Output: N.O. N.C
  • Wire connections: Integral 18” wiring with #6 spade lugs
  • Antenna: Attached wire or F connector
  • LED Indicators: Power channel 1
  • Polycarbonate enclosure
    • .......more details
Specification SheetInstallation Manual
MWT12B

Miller Edge Transmitter Binary Nema 4 Enclosure

  • The MWT12 safety edge transmitter is designed to provide wireless signal transmission form the safety edge to the motor controls.
  • It is easily mounted and wired to the gate or door edge sensor. When the sensing edge comes into contact with an obstruction a closed circuit signal is created and is sent to the transmitter.
  • The transmitter relays the information to the receiver and the receiver passes the signal along to the operator motor.
  • The gate or door stops movement and will then reverse the direction of travel.
  • Comes standard with a NEMA 4 weather-proof enclosure. The enclosure can be easily mounted with the four mounting holes and screws provided
  • Response time: 70 milliseconds
    • .......more details
Installation Instructions MWT12BSpec Sheet MWT12BFAQ MWT12B
MWTA12B

Miller Edge Transmitter with Low Battery Alarm Small

  • The transmitter comes standard with a NEMA 4 weather-proof enclosure
  • Compact design that allow for easy troubleshooting.
  • The transmitter has an audible alarm that activates when the battery has 25% of its life remaining
  • Easy to configure · Non-monitored system ideal for operators manufactured prior to: · Doors: August 2010 · Gates: January 2016 · NEMA 4 transmitter built to endure rugged environments
  • Power Source: (2) 1.5 volts AA lithium batteries
  • Input: 2-wire N.O. sensing edge
    • .......more details
Installation manualSpec sheet
MC22-2WIRE-LH-G

Miller Edge MC22 2-Wire Non-Monitored Left Hand Gray Includes Funny Flaps - Sold per Foot

  • Electromechanical sensing edge for use on Cornell doors. •The MC22 is manufactured to exact specifications. •The MC22 is completely flexible and will contour to curved surfaces. •Touch sensitive signaling allows immediate reversing or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Vertical or horizontal mount •One year warranty
Worksheet
MGR20-B-2U-PER-FT

Miller Edge Sensing Edge Round Black 2-Wire Universal Outlet Sold Per Foot

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
  • Non-monitored edge
  • Maximum length is 10ft (over 8ft requires LTL shipment at additional cost)
ME123-CA3

Miller Edge L-Shaped Aluminum Mounting Channel Sold by the Foot

AW-14

Miller Edge Air Wave Switch in ABS Box

  • Air pressure is lead via a hose or pipe to a diaphragm contact. This contact converts the positive or negative pressure into an electrical contact and pulse.
  • Molded enclosure
  • Applications: commercial sectional doors rolling doors and mass transit
  • Works on doors up to 60ft
  • Can be used with standard pneumatic hose and Miller Edge extrusion
  • Sensitivity: 2mm to 500mm
    • .......more details
Instructions ManualSell Sheet
ME123-YELLOW-U

Miller Edge Yellow Universal Outlet 2-Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
ME123-BLK-RH

Miller Edge Black Right Hand Outlet 2-Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
CG-4W-MON-BLK-RH

Miller Edge Clima-Guard 4-Wire Monitored Black Right Hand Outlet Sold by the Foot

  • Clima-Guard functions exactly like a pressure sensitive electric edge but with an added layer of protection.
  • The protective loop seal conforms to irregularities in the floor and helps prevent air infiltration and serves as a weather barrier.
  • ClimaGuard is made up of an ME112 sensing edge paired with a PVC loop seal that comes with a double slot mounting channel.
  • Electrical Configuration: Normally open
  • this edge comes with the channel
CG-2W-NM-BLK-LH

Miller Edge Clima-Guard 2-Wire Non-Mon Black Left Hand Outlet Sold by the Foot

  • Clima-Guard functions exactly like a pressure sensitive electric edge but with an added layer of protection.
  • The protective loop seal conforms to irregularities in the floor and helps prevent air infiltration and serves as a weather barrier.
  • ClimaGuard is made up of an ME112 sensing edge paired with a PVC loop seal that comes with a double slot mounting channel.
  • Electrical Configuration: Normally open
  • this edge comes with the channel
RLC-K36

Miller Edge Light Curtain Non- Monitored 3ft NO/NC

  • Light curtain made up of a series of thru-beam photo eyes designed to provide a dense barrier of protection for motorized or high speed doors.
  • Ideal for environments that require expanded protection for protruding parts that may not be detected by standard single-beam photo eyes mounted 6" above the floor.
  • Ideal for pre-2010 installations not requiring a monitored solution.
  • Ability to span up to 32' wide
  • Universal mounting brackets included
  • IP67 waterproof housing
    • .......more details
AW-12A

Miller Edge Air Wave Switch in NEMA 4 Enclosure

  • Air pressure is lead via a hose or pipe to a diaphragm contact. This contact converts the positive or negative pressure into an electrical contact and pulse.
  • Applications: commercial sectional doors rolling doors and mass transit
  • Works on doors up to 60ft
  • Can be used with standard pneumatic hose and Miller Edge extrusion
  • Sensitivity: 2mm to 500mm
  • Ambient temperature range: -49F to 180F
    • .......more details
Instructions ManualSell Sheet
PS-20A

Miller Edge Pneumatic Air Switch in ABS Enclosure

  • Pneumatic switch offering a reliable low cost alternative to a standard electric sensing adge.
  • When attached to a hose inserted into the existing weather stripping the PS-20A acts as an effective sensing edge on doors up to 18ft in length.
  • Applications: rolling doors sectional doors and mass transit.
  • Electrical configuration: 3-wire SPDT
  • Temperature range: -20F to 158F
  • Max pressure: 20 PSI
    • .......more details
Installation Manual
MIRCU-02

Miller Edge Universal Non-Monitored Interface

  • Converts a monitored pulsed signal to a non-monitored normally open signal
  • Creates a Fail Safe signal; reports a fault when power is lost
  • Ideal for use with pre-2010 commercial door operators
Installation instructionsSell sheet
MLC-K72

Miller Edge Light Curtain Monitored 6ft Pulsed

  • Light curtain made up of a series of thru-beam photo eyes designed to provide a dense barrier of protection for motorized or high speed doors.
  • Ideal for environments that require expanded protection for protruding parts that may not be detected by standard single-beam photo eyes mounted 6" above the floor.
  • Ability to span up to 32' wide
  • Universal mounting brackets included
  • IP67 waterproof housing not recommended for carwash applications
  • Operating temperature: -40F to 140F
    • .......more details
Installation manualSell sheet
MT22-GRAY-RH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot Gray

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MWRTA12B

Miller Edge Wireless Transmitter with Audible Alarm and 1 Channel Receiver

  • For 2-wire edges
  • Was previously MWRTA02A now has a new board making installation easier
  • Includes single channel receiver (MWR12A) and transmitter (MWTA12) with audible low battery alarm.
  • This feature that activates when the battery has only 25% of its life remaining indicating the battery should be replaced. The alarm sounds for 5 to 10 seconds at 1 to 2 minute intervals.
  • The receiver operates on either 12 or 24 volt AC/DC and provides N.O. or N.C. output.
Specification SheetInstallation Manual
RLC-K72

Miller Edge Light Curtain Non- Monitored 6ft

  • Light curtain made up of a series of thru-beam photo eyes designed to provide a dense barrier of protection for motorized or high speed doors.
  • Ideal for environments that require expanded protection for protruding parts that may not be detected by standard single-beam photo eyes mounted 6" above the floor.
  • Ideal for pre-2010 installations not requiring a monitored solution.
  • Ability to span up to 32' wide
  • Universal mounting brackets included
  • IP67 waterproof housing
    • .......more details
Installation manualsell sheet
