Home Your Search Garage Door Garage Door
CP-LX100

Lynx Control Board with Cover for UL325 models

  • For all voltages
Programming instructions
HD3115

Commercial Slide Lock for 3" track Long Throw 4" travel

  • Offset from inside face of door to lockbar: 1/2"
  • Bright zinc plated steel with spring actuated lock bar.
  • 4" of travel.
210339

Skylink Belt Gear with Holder LQ-803

H11G12

Hinge #12 x 11 gauge

  • 11 gauge # 12 hinge - 1.00 lbs
  • Bright zinc-plated steel construction
  • For use with 7/16" stem rollers
H11G06

Hinge #6 x 11 gauge

  • 11 gauge #6 hinge - 0.79 lbs
  • Bright zinc-plated steel construction
  • For use with 7/16" stem rollers
DM32-125

Cable Drum Standard Lift 32' 800-32 (1-1/4") Pair Torque Force

  • 32 ft Standard lift aluminum die cast alloy cable drums for 1-1/4" shaft.
  • Pair includes (1) LH & (1) RH. Color coded: Red=LH and Black=RH.
  • 3/8"-16 x 2" hardened cup point set screws installed with red heads.
  • Maximum Door Height: 32'-1".
  • Rated Lift per Drum: 1000 lbs.
  • Max Cable Diameter: 1/4".
    • .......more details
DM28VL-125

Cable Drum Vertical Lift 28' 1350-28 (1-1/4") Pair

  • 28' Vertical Lift aluminum die cast alloy for 1-1/4" shaft.
  • 3/8"-16 x2" hardened cup point set screws installed with red heads. -
  • Color coded: Red=LH and Black=RH. Pair includes (1) LH and (1) RH.
  • Max. Door Height: 28'-1".
  • Rated Lift per Drum: 1100 lbs.
  • Max. Cable Diameter: 1/4".
    • .......more details
DM120-T/FORCE

Cable Drum High Lift 120" D575-120-1 Pair Torque Force

  • 120" High Lift aluminum die cast alloy cable drums.
  • 3/8"-16 x 2" hardened cup point set screws installed with red heads.
  • Pair includes: (1) LH and (1) RH. Color coded: Red=LH and Black=RH.
  • Maximum high lift: 120".
  • Maximum door height: 144" + High Lift.
  • Rated lift per drum: 500 lbs.
    • .......more details
CHW401-114-TFRCE

Chain Hoist Wall Mount 4:1 1-1/4" 2000R Torque Force (126658)

  • 4:1 Reduced drive
  • Sprocket: 41B36x114 Bore: 1-1/4"
  • Includes: 26ft of hand chain 1/4" square key chain keeper and 3.6ft of #41 roller chain included with sprocket wheels.
  • Cross Reference: 2000R OMI 4006
DrawingSell sheet
GAREX-WINDOW

Garex Thermos Made-to-Order Size Special Order

  • Special order to suit customer's needs
K093A0763

LiftMaster Rear Housing KPW5 KPW250

  • This is a replacement Rear Housing KPW5 KPW250.
  • For use with various LiftMaster® Wireless Keypad Entry Systems
TDC12X1BMC

LiftMaster MAXUM Trolley DC Comm. Op 3/4HP Equivalent 120/240V 1PH 60 Cycles/Hr 1200LB

  • Smooth Start/Stop Operation - DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator.
  • Faster Speed - Average of 12” per second opening on sectional doors.
  • Battery Backup Option - (battery backup kit sold separately).
  • Floor-Level Wall Controller - 4-line LCD display gives you access to programming troubleshooting and diagnostics at floor level saving time and money.
  • Wi-Fi® and myQ® - Easily connect to myQ Facility via Wi-Fi for visibility into what is happening at your door and control it from your web browser; no need for additional hubs or accessories. Know what accessories activate the door (remote transmitter keypad etc.)
  • Drive Type 65:1 Gearbox with #50 Chain Output
    • .......more details
TDC_Installation-manualTDC_Manuel-installationData sheetFiche techniqueQuick connect guideGuide de connexion rapideOrdering guide
TDC1222-8

Liftmaster Comm. 8FT Trolley Angle set (10-5808-P x 2) and #41 chain pack (TDC41-10) ***Actual length 131"***

  • Double Angle Rails for doors up to 8'6" high
  • Includes #41 chain pack
STD-SS-MINI

Janus Mini Storage Latch Stainless Steel

  • Standard Stainless Steel latch
3055

End Stile Keyed L-Handle With Locking Cylinder and 7-1/2" Latch Mechanism

229557

Torque Force EZ Low Headroom Conversion Kit

  • Reduced headroom as low as 8"
  • Convert a standard lift door to a low headroom door without using an outside hookup configuration.
  • Easy to install 3 piece kit
  • Fits on 15" radius and 12" tracks
LM21XPBB

LiftMaster Extended Performance Fire Door Release Device with Battery Backup

  • UL864 Revision 9 compliant
  • Programmable DIP switch delay setting - either 10 20 30 or 60 seconds delay of door release to permit passage clearance
  • Inputs for normally open 2- or 4-wire detectors and 4-wire normally closed detectors
  • Trouble and alarm relays for communication with the fire alarm control panel if required
  • Audible trouble sounder to indicate when the release device is not operational
  • On board diagnostic LEDs for easy troubleshooting
    • .......more details
Installation Manual
41D7742-7

LiftMaster Travel Module

  • Fits models 8165 8355 & 8155W
306839

Bircher Hercules 2s Microwave Motion Sensor for Industrial Doors

  • Two completely independent programmable outputs for endless application scenarios
  • Highly flexible program settings utilizing both outputs are now easier to program
  • 23' (7 m) long cable for maximum installation flexibility
  • 6-wire cable using traditional wire colors & thicker wire gauge for easier installation
  • Pulse on exit feature
  • Differentiation between pedestrian and vehicle traffic
    • .......more details
Installation ManualSell SheetField Size
50-105

LiftMaster Black Coil Cord 4-Wire 18-ga 20 ft. Extended Curly Cord
