Home Your Search Chamberlain, LiftMaster
108D36

LiftMaster Light Lens (K108D0036-2)

  • Compatible with one light operators
  • Compatible with the following Liftmaster models: 1040 1045 1055 100WD 200WD 1140 1145 1155 110WD 210WD3 1240 1245 1255 215WD 15WD 1240R 1245R 1255R 985 1046 1146 1246 1246R 1056 1156 1256 and 1256R
  • Compatible with the following Chamberlain models: 2000 2100 and 2200
  • Dimensions are 7-1/4" wide X 4-3/4" high X 3" deep
877LM

LiftMaster Sec+ 2.0 Keyless Entry

  • Features Security+2.0™ rolling code technology
  • One-button-to-close feature
  • Temporary password option
  • Program code directly from keypad
  • Backlit keypad
  • Includes 9V battery
    • .......more details
877LM Manual
10-3209_GATE_BRKT

LiftMaster Gate Bracket

  • Fits SL580GL SL595GL and new IHSL24UL INSL24UL models
10-30701M

LiftMaster Chain Guide Tray for SL595

  • The tray located between the 2 chain guides.
  • Chain guides are not included.
10-12360

LiftMaster Universal Hood Angle Mounting Bracket 10-12360M1

  • Heavy gauge steel bracket for vertical or horizontal mount on either front or top of coil on a rolling door.
  • Has a variety of mounting hole patterns compatible with many OEM manufactures
  • For use with J H DJ DH
  • May be welded
08-11012

LiftMaster Bevel Gear 5/8" ID

  • Fits LiftMaster GH operator
HCTDCUL

LiftMaster Commercial High Traffic O/H Op. HCT Head Only 0.5 HP 120/230V 1PH BBU w/Eyes

  • Selectable Speed control opens up to 11" per second 25% faster than industry average to keep traffic flowing.
  • Low-Profile Design installs easily in tight applications at only 8" in height.
  • myQ® Technology enables you to securely control and monitor your gate operator from anywhere. (Cellular data or Wi-Fi® connection required).
  • Included: CPSUN4G Monitored Commercial Protector System® increases entrapment protection with through-beam infrared sensors with heavy-duty housings and brackets; NEMA 4 Rated; Maximum Range: 45 ft.
  • Security+ 2.0® On-Board Radio Receiver: Tri-Band 310/315/390 MHz frequency up to 50 remote controls (unlimited with 811LM/813LM)
HCTDCUL Installation ManualHCTDCUL Manuel InstallationSell sheetBrochure
HCT08

LiftMaster HCTDCU Rail Only for 7'6" Door

  • Yellow zinc dichromate premium rail finish offers maximum rust protection in open-air environments.
  • Heavy-duty 12-gauge C channel corrosion resistant steel track.
  • This DOES NOT include the head unit
811LMX

LiftMaster 1-btn Dip-Style Transmitter Sec+ 2.0 Backward Compatible

  • LiftMaster Programmable DIP single-button remote control.
  • Programmable to be: Encrypted DIP Security+2.0 (811LM) - Default 315 MHz DIP (361LM) 390 MHz DIP (61LM)
  • Ideal for applications such as gated communities or commercial applications requiring a large number of remote controls for a common entrance.
  • Compatible for cloning with 892LT & 894LT Learning Remote Controls.
  • Easy to program to previous technology.
  • Battery: CR2032 •
    • .......more details
Programming instructionsInstructions de programmationProduct guide
LMSC1000

LiftMaster RFID Long Range Vehicle Access Card Reader

  • Easy wall or post mount vehicle tag/prox card reader can service an entire facility parking garage gated community/HOA or guarded properties.
  • Integrates into (CAPXL CAP2D) Liftmaster PPWR Passport Receiver and LiftMaster CSW24U 24 VDC Commercial Swing Gate Operator CSL24UL HCTDCUL systems to give access via encrypted-digital code.
  • Opens swing or slides gates from 20-30 feet distance
  • 26-bit Wiegand Interface console
  • Encrypted binary protocol signal
  • Helpful Programming/Testing/Function tri-color LEDs on both reader face and Wiegand console
    • .......more details
Installation manualManuel d'installationSell sheetBrochureWiring the LMSC1000 to KPR2000 Raccordement éléctrique du LMSC1000 au KPR2000
10-10355

LiftMaster Solenoid Link

TDC12S1BMC

LiftMaster MAXUM Trolley DC Comm. Op 3/4HP Equivalent 120/240V 1PH 30 Cycles/Hr 1200LB

  • Smooth Start/Stop Operation - DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator.
  • Faster Speed - Average of 12” per second opening on sectional doors.
  • Battery Backup Option - (battery backup kit sold separately).
  • Floor-Level Wall Controller - 4-line LCD display gives you access to programming troubleshooting and diagnostics at floor level saving time and money.
  • Wi-Fi® and myQ® - Easily connect to myQ Facility via Wi-Fi for visibility into what is happening at your door and control it from your web browser; no need for additional hubs or accessories. Know what accessories activate the door (remote transmitter keypad etc.)
  • Drive Type 65:1 Gearbox with #50 Chain Output
    • .......more details
TDC_Installation-manualTDC_Manuel-installationData sheetFiche techniqueQuick connect guideGuide de connexion rapideOrdering guide
CHAINTENSDC

LiftMaster Chain Tensioner 1" MAXUM DC

  • For use with various LiftMaster® MAXUM DC Standard-Duty and Industrial-Duty Commercial Door Operators; manufactured after 2023 only.
  • Spreader for Maxum operators and 1" door shaft
JHDC12S1BMC

LiftMaster MAXUM Jackshaft 3/4HP 120/240V 1PH DC Operator 30 Cycles/Hour 1200LB

  • New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
JHDC_Installation-manualJHDC_Manuel-installationData sheetFiche techniqueQuick connect guideGuide de connexion rapideOrdering guideSprocket recommendations
15-50B24LGH

Sprocket 24 Teeth 1" Bore 1/4" Keyway 2-SS

041C0010

LiftMaster Chain Spreader 3/4hp

  • For use with various LiftMaster® and Chamberlain® 3/4 HP Chain Drive Garage Door Openers
LJ8900W

LiftMaster Light Duty Jackshaft Door Op. for Sectional Doors

  • Ideal for smaller/lighter commercial doors with light duty cycle requirements
  • MyQ Technology Built-In Wi-Fi Real-Time Alerts
  • Smooth Start/Stop
  • Optional Accesories 877LM Keypad 827LM MyQ Remote LED light 485LM Battery Back-up 841LM Automatic Door Lock 480LMB Alternate Mounting Kit and LC-36A Light Curtain
  • Compatible remotes; 893MAX 891LM 893LM
Installation manualSell sheetBrochureGuide De Produit
81550

LiftMaster 1/2HP AC Belt Drive Wi-Fi with one light

  • Free MyQ® Mobile App so users know their home is secure.
  • Built-In Wi-Fi® for the easiest way to connect the garage.
  • Real-Time Alerts indicate the status of the garage door via email or push notifications.
  • Monitors and Controls the opener from anywhere using mobile devices.
  • Belt Drive system for quiet maintenance-free performance.
  • Security+ 2.0® safeguards garage access with every click a new code is sent to the Garage Door Opener ensuring the door does not inadvertently open.
    • .......more details
81550 Installation manual81550 Manuel InstallationProduct guideReceiver Logic Board Conversion ListComparison Chart
03-35711

LiftMaster Contactor Relay 24V

  • Contactor Relay Replacement Kit (24V 2NO+2NC)
02-711

LiftMaster Nema 7/9 Ceiling Switch Pull Control

  • Single Pull Switch Control
  • Hazardous Area Overhead Mt. (NEMA 7/9)
  • Die cast hazardous area enclosure
  • May be used in two different ways; as an OPEN only control (all LiftMaster operators) or as an OPEN/CLOSE control (only LiftMaster operators with types B2 and S2 control wiring). In the latter case pulling the cord will open a fully closed door close a fully opened door and reverse a closing door.
  • Pulling the cord whlie the door is opening will either have no effect (type B2 wiring) or will stop the door (Solid State Logic Control Board).
  • WARNING: When used on most industrial operators this control will not stop the door. Use another control that has a STOP button in conjunction with this control.
    • .......more details
