Devanco Canada - Get The Right Garage Door Opener‎ and Parts

RENO-BX4

RENO 11-Pin Amphenol Style Connector 12-24V Single Channel Loop Detector

The Model BX is a full featured single channel dual output vehicle detector that incorporates the reliable vehicle detection technology found in all of Reno A & E s vehicle detectors.
Eight detection sensitivity levels are selectable by means of a front panel mounted rotary switch external dip switches
Dimensions: 11-Pin Models - 3.00 inches (7.62 cm) high x 1.75 inches (4.45 cm) wide x 4.30 inches (10.92 cm) deep

Installation Manual Sell Sheet

SMT7000TP5

Telco Thru Beam Transmitter DC M18 5M Cable

Supply Voltage: 10 - 30 V dc
Light Source: Infrared (880 nm)
Control Feature: Test Input
Sensing Range: 20 m
Housing: M18 x 1 Plastic
Connection: 5m cable

.......more details

02-403P

Push Button Control Station 3-Button Surface Mount NEMA 4/12 O/C/S Green Black Red Part # XALD03H7

Open/Close/Stop allows complete control of the door.
Compatible with all commercial door operators.
NEMA 4 4X 12 13
Outdoor surface mount station with polycarbonate enclosure part # XALD03H7

Sell sheet

6062

Programmable Timer *** To Extent of Inventory

12VDC or 24VDC operation is selectable
Functions include: One shot Delayed release Delayed operate Delayed pulse and Pulse / Flasher.
Momentary relay activation at the end of a desired timing cycle eliminating the need for having to use 2 timers to achieve this function
LED indicates relay is energized
Form C relay contacts are 8 amp at 120VAC / 28VDC

Installation instructions

02-103

Push Button Station 3-btn Surface Mount Metal Housing

PBS-3
Open-Close-Stop
Momentary contact
Nema 1
Dimensions: 5-5/16" H x 2-3/8" W x 1-13/16" D

Z9962

L5 Operator Mounting Bracket

Compatible with L5 Jackshaft operators
Eliminates the need for a spreader arm by mounting a fixed bearing on the operator adjustment plate preventing the torsion shaft and operator from moving closer together
Precise chain tension adjustments through the adjustment bolt
Maintains parallel alignment between the operator output shaft and the door’s torsion shaft during chain tensioning
Operator installation is made easier by allowing the bracket to be hung on the torsion shaft via the bearing supporting its weight during fastener installation thereby removing the need to hold the operator manually
Has physical tick marks on both sides of the bracket and at the center of the bearing plate to indicate the torsion shaft’s center position allowing bracket to be accurately mounted prior torsion shaft installation

.......more details

Z9961

Maxum Operator Mounting Bracket

Compatible with MAXUM® Jackshaft operators
Eliminates the need for a spreader arm by mounting a fixed bearing on the operator adjustment plate preventing the torsion shaft and operator from moving closer together
Precise chain tension adjustments through the adjustment bolt
Maintains parallel alignment between the operator output shaft and the door’s torsion shaft during chain tensioning
Operator installation is made easier by allowing the bracket to be hung on the torsion shaft via the bearing supporting its weight during fastener installation thereby removing the need to hold the operator manually
Has physical tick marks on both sides of the bracket and at the center of the bearing plate to indicate the torsion shaft’s center position allowing bracket to be accurately mounted prior torsion shaft installation

.......more details

Installation Manual

50-101-2

Exterior 3-Wire Air Switch SPDT with Plastic Housing Mosley

Nema 4
3-wire air switch; 1-NO and 1-NC contact
Mosley
NO contact on Yellow and Green

QUICK_CLOSE

Commercial Quick Close Device / Universal Timer V8

This device will automatically close the door as soon as the vehicle passes through the safety beams.

Wiring Instructions Monitored connection Non-monitored connection

IS-2

Interlock Switch for Sectional Doors

Mounts on the door track to prevent the use of the operator when door is locked
Can be wired to a three button station
Demensions: 3" h x 3" w x 1-1/2" d

HD-15

Reflector Hood for 3" Round Reflector

Black/Charcoal

REEL-20

Devanco Take-Up Reel 2-Wire Metal 18-ga 20ft Black

18-gauge
20 ft extended
Take up reels are NOT recommended for use with any failsafe type edge. Use coil cord only.
Also called Reel cord
Comes with reset button for CSA conformity

02-403N4-XALD

Push Button Control Station 3-Button Surface Mount NEMA 4/12 O/C/S Black Black Red

Open/Close/Stop allows complete control of the door.
Compatible with all commercial door operators.
NEMA 4 4X 12 13
Outdoor surface mount station with polycarbonate enclosure Part # XALD03H7
Dimensions: 2.0" x 5.27" x 2.68" (H x L x W)

E3K-2018

Omron Retro-Reflective Photocell w/Built-In 10K Resistor UL325-2018 *Same as model E3K-R10K4-NR-1

Fully complies with UL325-2018 standard for gate ops. that use the 10K resistor method and also the Normally Closed method
Easy to wire terminal strip
Plug-in replaceable outputs
Range: 40ft
Power: 24-240V AC/DC
The E3K-2018 has a second relay to accommodate traditional dry contact for non-monitored applications.

.......more details

Wiring Diagrams Sell sheet

3EBX

Explosion Proof 3-Btn Pushbutton Control Station

Not rated for division or class
Three button O/C/S Nema-7/9
Surface mount
Dimensions: H=6-1/8" x W=3" x D=4-3/8"

PED72

Pedestal Post 72" Gooseneck Pad Mount

Black powder coat finish
Faceplate with universal hole pattern to fit almost any access device
2" x 2" square post
Neck is bent with a 6 in. center radius giving a tight professional look

RP-3002

Rubber Plug 1/2"

To plug end of 3002 gum hose

LSBLK

Loop Sealant Cartridge Black 29oz

Also available in grey (LSGRY)
Can be installed in sub-zero temperatures as long as the surface is clean and dry
Loop sealant gun sold separatley # LSGUN
