Devanco Canada - Get The Right Garage Door Opener‎ and Parts

DM120-T/FORCE

Cable Drum High Lift 120" D575-120-1 Pair Torque Force

120" High Lift aluminum die cast alloy Cable drums.
3/8"-16 x 2" hardened cup point set screws installed with red heads.
Pair includes: (1) LH and (1) RH. Color coded: Red=LH and Black=RH.
Maximum high lift: 120".
Maximum door height: 144" + High Lift.
Rated lift per drum: 500 lbs.
Maximum Cable diameter: 3/16".
Mounting: 1" solid shaft with 1/4" keyway.
Cross Reference: D575-120HL DNS 120 OMI 2700 5750-120

DM518-125

Cable Drum Standard Lift 18' D525-216-125 Pair Torque Force

18' standard Lift aluminum die cast alloy.
Pair includes: (1) LH and (1) RH.
Color coded: Red=LH and Black=RH
Max. Door Height: 18'-1" Rated Lift per Drum: 750 lbs.
Max. Cable Diameter: 3/16".
Mounting: 1-1/4" solid shaft with 1/4" keyway

.......more details

CB18B0500-KOR

Cable 1/8" 7x19 500' Galvanized Supreme

Galvanized Cable 1/8" 7x19 500ft spool.
Cable break strength: 2000 lbs
A higher quality cable compared to the Chinese cable.
Meets endurance test requirements of over 35000 work cycles
Lubricated for flexability and longer service life

Comparison charts

CB18A500-KOR

Cable 1/8" 7x7 500' Galvanized Supreme

Galvanized cable 1/8" 7x7 500ft spool.
A higher quality cable than the Chinese cable.
Meets endurance test requirements of over 35000 work cycles
Lubricated for flexability and longer service life

Comparison charts

CABLE_532SS-500

Cable 5/32" 7x19 Stainless Steel 500ft

Comparison charts

HD8460-KYD-ALIKE

T-Handle Cable Lock System 1-3/8"- 2" ** Keyed Alike **

Complete cable locking system for a 1-3/8" or 2" door Keyed alike
System includes: Auto Latch Striker Keeper T-Handle keyed with 4-1/4" shaft Inside release handle 3/32" cable and all required hardware.
Also works for for 1-3/4" doors
T handle KA5 = keyed alike increment of 100 (5 different combination box (20 of each #)

R5210

Pulley 4" Zinc Plated Steel with Sheave Strap

Bored for 3/8" diameter bolt
Maximum cable diameter: 1/4"
Hardened inner race
Includes fork

HD8460-200

T-Handle Cable Lock System 2"

Complete cable locking system for a 2" door.
System includes: Auto Latch Striker Keeper T-Handle keyed with 4-1/4" shaft Inside release handle 3/32" cable and all required hardware.
Also works for for 1-3/4" doors

BK028/PR

Commercial Light Duty Bottom Bracket 2" Track 13-g BB-90 Sold as a Pair

For 2" track with 7/16" diameter stem rollers
Milford pin cable attachment
For 1-3/4" doors
Size: 8" tall x 3" wide
Includes 1 left and 1 right hand bracket
BB-90 MPL

.......more details

R5207

Pulley 4" Zinc Plated Steel

Bored for 3/8" diameter bolt
Maximum cable diameter: 1/4"
Hardened inner race

CBA18B08

Cable Assembly 1/8" 7x19 114" Sold per Pair

Galvanized cable assembly for 8ft door (114" = 9'-6")
Aircraft cable made of 19 wires per strand and 7 strands per cable
Sold as a pair
Same as part number 458

Z9959

Tension Release Hub Torsion Spring Back Winder

Safely back wind the torsion springs in tricky “slipped cable” situations
Easily slide and tighten the solid steel hub on either end of the torsion shaft to back wind the torsion springs using a 5/8" winding bar unwrap and re-install the cables on drum
Can be used on 1" solid or hollow shafts

HW0427-LH

SteelCraft Commercial Bottom Bracket Left Hand Only

Left Hand bracket only
Can be used for both 2" and 3" tracks
To be used on door tracks that are installed wide enough to accomodate the side cable pulley
Door hardware must start with a #1 hinge on the bottom panel for both 2" and 3" hardware
Adjustable cable can level door from the ground
Heavy gauge steel construction

.......more details

HW0429-RH

SteelCraft Commercial Bottom Bracket Right Hand Only

Right Hand bracket only
Can be used for both 2" and 3" tracks
To be used on door tracks that are installed wide enough to accomodate the side cable pulley
Door hardware must start with a #1 hinge on the bottom panel for both 2" and 3" hardware
Adjustable cable can level door from the ground
Heavy gauge steel construction

.......more details

D525-54-HL

Cable Drum High Lift 54" D525-54HL Torque Force Pair

Maximum hi-lift: 54"
Capacity: 500 lbs per drum
Max. cable size: 3/16"
Cable length: Floor to shaft center 66" minus amount of Hi-Lift
Cross reference: DNS 54 OMI 54HL M134-1375

D525-216-1

Cable Drum Standard Lift 18' 3-SS Torque Force Pair

18' standard Lift aluminum die cast alloy with 3 set screws.
Pair includes: (1) LH and (1) RH.
Color coded: Red=LH and Black=RH
Max. Door Height: 18'-1" Rated Lift per Drum: 750 lbs.
Max. Cable Diameter: 3/16". Mounting: 1" solid shaft with 1/4" keyway
Cross Reference: DM518 DNS 5-18 OMI 2200

.......more details

D400-144-1

Cable Drum Standard Lift 12' Torque Force Pair

12 ft Standard lift cable drum. Aluminum die cast alloy.
Max. door height: 12'-1".
Rated lift per drum: 375 lbs.
Max. cable diameter: 5/32".
Mounting: 1" tube or solid shaft with 1/4" keyway.
Cross references: DM413 DNS 4-13 OMI 2100.

.......more details

D800-120-125

Cable Drum High Lift 800-120 1-1/4" HL Pair

Adjustable cable attachment with screw
Made of aluminum
High Lift capacity: 120" max
Flat capacity: 266" max
Rating: 2200 lb per door max
Keyway: 1 KW of 1/4" width

.......more details

BK150/PR

Residential Bottom Bracket BB-100 sold as a pair

For use with 2" rollers
Works on 1-3/8" 1-1/2" 1-3/4" and 2" doors
13 gauge residential bottom bracket that secures to the bottom of the door allowing the cable to be attached to the door for lifting
Same as part number 263

CBA18B07

Cable Assembly 1/8" 7x19 102" Sold per Pair

Galvanized cable assembly for a 7ft door (102" = 8'6")
Aircraft cable made of 19 wires per strand and 7 strands per cable
Sold as a pair
Same as part number 457
