Home Your Search Emx Industries Inc.
5415-2

EMX RAVEN Dual Relay Microwave Motion Sensor

  • Distinguish between vehicles and pedestrians
  • Two configurable relay outputs
  • Adjustable sensitivity and cross traffic suppression
  • 8-23 ft (2.5-7 m) mounting height
  • Optional remote control for easy programming
ULTRA-II-D-TEK

EMX Industries Plug-in Loop Detector (2663-1)

  • Features a slim design that is compatible with most gate operators that require a dry contact relay input.
  • No harness required; comes with terminal screw adaptor
  • ULTRAMETER™ (displays optimum sensitivity setting / diagnostic aid)
  • Frequency count/reset switch
  • 10 sensitivity settings
  • Loop diagnostics
    • .......more details
USVD-4X

EMX Ultra Sonic Vehicle Detector 2700-1

  • The USVD-4X Drive Thru Vehicle Sensor uses patent pending Triangular Planar Array (TPA) technology to detect the presence of a vehicle.
  • The USVD handles any drive thru operation such as fast food banking pharmacies car washes and parking garages.
  • The USVD is simply mounted on a post or order box and aimed at the location where a vehicle would pass to initiate a transaction. No set-up or adjustments required.
  • Aux. relay settings for pulse on ENTRY EXIT or BOTH
  • Output delay option for 1 2 and 4 seconds
  • Operating range: 1ft. – 5ft.
    • .......more details
Installation ManualSell Sheet
TSTL

EMX Test Loop

  • Electrical diagnostic tool for loop and vehicle detectors
  • Two-wire: red and black
  • Dimensions: 1.25 inches (H) x 1.25inches (W) x .75inches (D)
  • Compatible with most brands of loop detectors
CHIME-100

EMX Vehicle Alert with Adjustable Volume Control

  • Provides an audible chime when a vehicle first pulls in front of the vehicle detector
  • It is a compact audio alert device designed for loud work environments
  • It has an adjustable volume control and can reach volumes of 100 dBA at 5 ft away making it easy to hear in noisy areas
  • It is easy to install with two mounting tabs and includes 25 ft of durable cable
  • The CHIME-100 also features an output relay for daisy-chaining additional electronics and 6 melodies to choose from
  • Has 1 relay output
    • .......more details
5416-2

EMX RAVEN Programming Remote

  • Makes it easy to set up and make adjustments to all key parameters of the RAVEN motion detector while at ground level
  • Remote sold separately
Quick Start Guide
CELLOPENER-365

EMX GSM Access Control & 365 Day Timer 2000 Users EMX-5431-1

  • Up to 2000 Programable Users
  • Weekly & 365 Day timer
  • AutoAdjust for Day Light Savings Time
  • Remote Programming From Anywhere in the World
  • GSM SIM Card Included
  • Cell Phone SMS Activation Required
    • .......more details
ULT-PLG-D-TEK

EMX Industries Ultra Loop Plug-In Loop Detector Dual Output 2670-1 (Replaces 2500-2346-LP)

  • Trademarked Detect-on-Stop technology
  • Compatible with the Linear (OSCO) with APEX/APEX II controller
  • Also Compatible with -Advanced Access Automation/FAAC CSL2000 CSW2000 RSW1000 -All-O-Matic SL100-DC -Chamberlain/Elite SL3000 CSW200 - Intelligent Systems IQ500 IQ5000 -SECOM Late Model operators with 10-pin Molex connectors -Rotary Gate Systems SL1000R SL1000C SL1000I -TyMetal TYM 1000 TYM 2000 -Viking Access Models L-3 F-1 T-21...
  • Sold-state output indicating vehicle presence
  • Ignore cross traffic in tight spaces
  • Select for automatic sensitivity boost (ABS) delay fail safe/fail secure
    • .......more details
LRS-LC

EMX Logic Controller

  • For use with the Loop Replacement System (LRS-C1) Magnetoresistive Vehicle Detector Control Unit
  • Connects two stand-alone sensors to expand the detection area
  • Works with LRS-DB (LRS-DB-50 or LRS-DB-100) Direct Burial or LRS-FP Flat Pack (LRS-FP-50 or LRS-FP-100)
  • Logic Interface allows one (1) or two (2) sensors to be connected to one (1) output
  • Provides six (6) selectable logic functions and two (2) separate relay outputs
  • A/B directional logic can be selected with an output for each direction of travel as a vehicle passes over two sensors
    • .......more details
LRS-FP-100

EMX Sensor Flat Pack 100ft Wire

  • Lead probe ONLY. Requires the LRS-C1 detector
  • Three-dimensional presence detection of vehicles
  • Select X Y Z axis independently
  • Stand-alone sensor
  • Sensor stores ambient background and settings in non-volatile memory
  • Includes sensor and 100 ft of lead wire
    • .......more details
PROBE-150

EMX CARSENSE-101 Direct Burial Probe with 150' Lead Wire

  • Wand only
  • Requires CS101 (Carsense-101)
IRB-TX

EMX Industries Transmitter Board Only for IRB-4X *** No Longer Available

ETM17-24V

EMX Digital Timer *** No Longer Available

  • The ETM-17 series are panel mount digital timers the can be operated in 12V dc or 24V ac/dc power supply ranges depending on model ordered.
  • The output is a form “C” relay capable of 16A@ 30VDC.
  • Internal battery for memory backup of programming in the event of power failure.
  • Designed with 17 ON/OFF events per day and 15 combinations of daily programs for the best flexibility to the user.
  • Manual or Auto mode
KPX-100

EMX Access Control Keypad

  • Stainless steel face with metal backlit keys
  • Anodized and powder coated steel outer housing that is vandal and weather resistant to IP66 (all weather)
  • Dual relay outputs
  • Over 100 Million 4-8 digit codes
  • 12-24V AC/DC operation
  • 100 user codes on Relay 1; 10 users relay 2
    • .......more details
NIR-HD

EMX Industries NIR Hood Cover Steel

  • The hood keeps rain and other debris from distorting or blocking the photo beam.
  • It also helps to keep the sun from glaring off the reflector and disturbing the beam's reflection.
  • Replaces the mounting bracket that comes with the sensor.
  • Comes with Hood two sets of nuts and bolts and a plug
VMD202-50

EMX Vehicle Motion Detector Probe with 50ft Lead Wire

  • The VMD202 Vehicle Motion Detector is the most advanced single-piece vehicle motion sensor on the market today.
  • The probe and its electronics are housed in a slim design that is buried next to a driveway.
  • The VMD202-R Sensitivity Remote Control (sold separately) makes installation and fine tuning simple
  • Probe assembly and wire are water tight and direct burial compatible
  • Harness is pre-wired onto lead wire for easy installation
  • Settings are placed in a non-volatile memory in case of power failure
    • .......more details
IRB-RET-HD

EMX Industries Steel Protective Hoods Only Black Fits Old Style IRB-RET Only *** No Longer Available

  • Protective Hoods for the Universal Retro-Reflective Monitored Photo Eye System (Item #IRB-RET) by EMX
  • Easily installed using the existing mounting holes of the Photo Eye
  • Constructed of zinc plated steel
  • Black powder-coated finish
  • Will NOT fit the new IRB-RET UL325-2018 units
D-TEK-LM

EMX Industries Plug-in Loop Detector for Liftmaster operators ** To extent of inventory

  • Plug-in Loop detector for SL575 SL585 SL595 BG770 BG 79024VAC
  • Works with most LiftMaster gate operators
  • Won't work with Elite Series Mega Arm Slide & Swing
  • Simply plug it into the harness already in the operator
  • Loop lead-in wires connect to operator terminal strip
  • Gold plated control contacts
    • .......more details
Installation ManualSell Sheet
MKTG-1031-1

EMX Pastic Screw for IRB-4X2

  • Replacement screw only
LD-11B

EMX Base Socket 11-Pin DIN Rail Mountable Black Block Style

  • For use with D-TEK detectors
  • Special Order Only
  • Narrow profile
