27021

Doorlec Electric Motor TEFC 1/2HP 115/230V DC201

Wiring diagram for 120V Wiring diagram for 230V Motor Replacement Chart

1044622-REFURB

FAAC 400 Hydraulic Swing Gate Operator 115V Reburbished

Refurbished unit.
Tank body

TCG-2

LiftMaster Tri-Code Commercial Receiver ** DISCONTINUED

Two channel commercial receiver compatible with Linear Delta Multi-Code and Stanley radios.
Six 3' wired leads

Installation Manual

27175B

Genie Carriage Slide Only

Carriage NOT included. Carriage part number 20462R
Compatible with Genie GPS and PMX belt drive models

20386R

Genie Sequencer Board AC Screw Drive

For Genie Screw Drive garage door opener models: PRO95 CM8600 CM7600 Series II ISL950A IS550
Replaces part number 31184R

Z9200

Cable Snubbers Sold as a Pair

Prevents slack from forming in cables
Sold in pairs

Installation Instructions

SN1150050

LiftMaster Main Processor Board for MiniKey

798

Fasteners Cotter Pin 3/32" x 1" 100/Bag

GH103-L5

LiftMaster Gearhead with Brake 1 HP 208/230/460V 3-Phase Logic 5 *** To extent of inventory

Includes CPS-U photoeyes

Installation Manual Manuel d'Installation Sell sheet Brochure

MA022

LiftMaster Arm Bolt

For use on Mega-Arm gate operator
Sold individually
5/16-18 x 29" hex head

831T

Allstar Stationary TransmitterO/C/S 3-Btn 1-Door 318 MHz 107483 *** To extent of inventory

Open/Close/Stop stationary remote for 1 door.
Designed for commercial automatic door and gate operator applications.
This transmitter can operate a single receiver connected to one operator
Compatible with 3-channel Allstar and MVP receivers
Easy access to battery and coding switch
Power: 9-volt battery

.......more details

Programming Instructions

IPAC

LiftMaster Internet Enabled Outdoor Access Control System with VoIP Technology

LiftMaster® IPAC (Internet Protocol Access Control) is the first Internet-enabled outdoor access control system with Voice-over Internet Protocol (VoIP).
By harnessing the power of a high-speed connection IPAC’s innovative technology allows you to work smarter and more efficiently and its contemporary design features a durable enclosure which enhances your property’s image.
Make updates 24/7 through an IP address (no software to install) so you never have to take IPAC offline.
Manage resident info from any browser on your LAN so you do not physically visit the unit.
VOIP technology eliminates long distance fees and will be replacing old analog phone lines.
50000-resident capacity so you’ll never run out of system memory.

.......more details

Installation Manual Sell Sheet

PRO-HB-7511R-LH

Micanan 3/4HP 115V 1P Hoist Operator with Brake and Mechanical Contactor Left Hand

Continuous duty belt drive jackshaft operator with emergency chain hoist
Includes solenoid brake
On-Board receiver holds up to 20 transmitters

Installation manual Specification sheet

MK-00719

Micanan Replacement Antenna for On-Board & External Receiver

Approx. 8" long

T755L5

LiftMaster 3/4 HP 575V 3p Commercial Trolley Operator Logic 5 ***No Longer Available

Low profile trolley operator with brake included

Installation Manual Manuel d'Installation Sell sheet Brochure

765

Fasteners Serrated Flange Nut 3/8-16 1000/Box

Serrated flange face to provide locking

764

Fasteners Serrated Flange Nut 5/16-18 1000/Box

CBS-338

Center Bearing Support 3-3/8" 8-gauge with Bearing Sold per Piece

Heavier gauge allows for use in both 2" commercial or 3" industrial applications
Sold per piece
For 1" shaft
Double clipped ends

29-31229

LiftMaster Relay 24VDC 30A SPDT 1-Phase only

C-relay for model T operators 10A

SSZP24

Solid Shaft 1" Keyed Zinc Plated 24'

114

Lag Screw Hex Washer Head 1/4" x 1-1/4" 1000/Box

7/16" head
Serrated

SSZP12-6

Solid Shaft 1" Keyed Zinc Plated 12'-6"

SSZP10-6

Solid Shaft 1" Keyed Zinc Plated 10'-6"

SSZP6-6

Solid Shaft 1" Keyed Zinc Plated 6'-6" ** to extent of inventory

SSZP8-6

Solid Shaft 1" Keyed Zinc Plated 8'-6" (102")

6X42PO50

Devanco Loop 6' x 42' pave-over 50' lead-in

Ideal for use on with gravel driveways or sufaces that are to be asphalted
Features a twisted lead-in to reduce the chances of interference and false detections.
Direct burial loops should be buried approximately 6" deep

Installation Instructions Instructions d'installation Spec Sheet Brochure Loop Placement Guide Guide de positionnement des boucles

RBH751L5-RH

LiftMaster 3/4 HP 115/230 VAC 1 PH Commercial Hoist Operator Logic 5

H-style operators include a floor level chain hoist to ease manual operation in an emergency or power outage.
The operators are typically mounted to the wall when used with larger sectional overhead doors with vertical or high lift and mounted to the wall or the front of the hood when used with rolling doors and grilles.
H operators are attached to the door jackshaft to indirectly drive the door.
With the addition of the 828LM MyQ technology enables the user to monitor and control their operator and light with their smartphone tablet or computer.
Alerts can be received as email or pop-up (push) notifications on a mobile device ensuring the status of your commercial door.
Security+ 2.0™ safeguards your facility – with every click a new code is sent to the commercial door operator so the door opens only for you.

.......more details

Installation Manual Manuel d'Installation Sell sheet

CAR2U-RPTR

LiftMaster Lear CAR2U Repeater *** No Longer Available

� The Lear Car2U® repeater kit allows compatibility between new Chamberlain® Sears Craftsman® or LiftMaster® Garage Door Openers and the Car2U system in your vehicle. · The Car2U system is a garage door opener integrated into your vehicle. · The Lear Car2U kit contains a transmitter and a detailed instruction manual.

Programming Instructions

02-409B

LiftMaster Key Switch with Best Cylinder

Two Position Key Control Station
Outdoor Surface Mt. (NEMA 4/12)
Tamperproof
Die cast metal enclosure with BEST cylinder (construction core included)
OPEN/CLOSE spring return to center (OFF) key removable in center position only. Should only be used on operators wired for constant pressure to open and close (all LiftMaster industrial operators with type D control wiring).
Dimiensions: 3" x 3.2" x 4.2"

.......more details

T501L5

LiftMaster 1/2HP 115/230 Volt 1Ph Commercial Trolley Operator ***NLA

New Logic 5
Suspended from the ceiling the operators are used on sectional overhead doors with standard lift.
T operators are directly attached to drive and control the door.
MyQ® Technology enables you to securely monitor and control your facility operator and lights with your smartphone tablet or computer for greater peace of mind.
Alerts can be received as email or pop-up (push) notifications on a mobile device ensuring the status of your commercial door.
MyQ Mobile App is a free download with no annual activation fee.

.......more details

Installation Manual Manuel d'Installation Sell sheet Brochure

K2A761

LiftMaster Coaxial Cable

For use with 315MHz receiver

CH501L5-LH

LiftMaster Hoist Op. with Carwash Mod. 1/2 HP 115/230 VAC Logic 5 Left Hand

Industrial Duty Hoist Operator with Damp Environment modification.
Comes with CPS-UN4 photoeyes

Installation Manual Manuel d'Installation Sell sheet Brochure

CH751L5-LH

LiftMaster Hoist Op. with Carwash Mod. 3/4 HP 115/230 VAC Logic 5 Left Hand

Industrial Duty Hoist Operator with Damp Environment modification.
Comes with either CPS-UN4 or CPS-RPEN4 photoeyes

Installation Manual Manuel d'Installation Sell sheet Brochure

41B4103

LiftMaster Service Belt Tensioner

K21-36793

LiftMaster Transformer 208-230/460 Volts 20Va

230/460V PRIMARY 24V SECONDARY 20VA

178B35

LiftMaster Curved / Bent Arm Kit (41B0035B)

Will work with most residential garage door openers
Also known as: 4178B0035B 178B32 41B0035B 4178B35 178B35 012385990357 178B35B

26-94625

Truck Door Top Panel (15" x 98") for Whiting DryFreight

These panels are cut to an extra wide width to fit wider vehicle applications
Interlocking tongue and groove design for weather-tight joint and proper alignment.
.75" thick 7 ply exterior grade medium density plywood
Primer finish

71B120G

LiftMaster Brake Kit 115V with Solenoid Field Install SL585 and SL595

Instruction Manual

MA021

LiftMaster Nylon Arm Nuts 50/Pkg

For barrier gate models MADCBB MATDCBB MASDCBB & MASTDCBB

41A6408

LiftMaster Travel Module (98022 8500 3800P 3800PLD & 3900) - 41B8861

Works on model 8500

Programming Instructions Instructions de programmation

MB-01001

Micanan Electric Motor Only 1/2HP 110/220V 1PH

Base Mount motor O.D.P. FR56
Used on Micanan's T TB APT J EJ H EHJ HHD & SD

MP-00001

Micanan Timer to Close 24V Modification

3-button o/c/s function timer will start counting from fully open reverse and reset from any device
24V modifictation available on control circuit ( R) and ( M) and is included with the new full function smart board (E)

IS-3

Interlock Switch for Rolling Steel Doors / Grills

Prevents the control of the operator when the door is locked.
The switch is a normally closed contact which is connected to the operator interlock terminal.

MK500GS

LiftMaster MiniKey Stand-Alone Keypad System ** No Longer Available

Self-Contained Keypad System for Door and Gated Entrances
500 Code capacity
Grained stainless steel Surface Mount
Dimension: 4-1/2" H x 4-1/2" W x 3-1/2" D
Same as SN7000255
Sentex Keypad

.......more details

Installation Instructions Programming Instructions Sell sheet

AIRSWITCH008

Manaras Metal Case for AIRSWITCH007

AIRSWITCH007

Manaras Exterior Adjustable Air Switch SPDT

To be used with metal case part # AIRSWITCH008

19-48047M

LiftMaster Roller Chain #48x47

#48 x 47 pitch with master link
Internal reduction chain
Length is 24"

27-20100

Truck Door T-Style Spring Assembly 60" Long

Wire thickness: .24"
Inside diameter: 1.75"
Includes bolt plug and winding plug wound onto spring for stronger design
Cross reference: T#51042 W#2701

27-20112

Truck Door W-Style Spring Assembly Curbside 33" Long

Wire thickness: .182
Spring length: 33 inches long (assembled length)
Inside diameter: 1.188
Includes cable drum and bearing assembly winding cone wound onto spring for stronger desgn and internal spring spacer.

MV-00023

Micanan 1-Door O/C/S Transmitter CT-1 313 MHz

Programming Instructions

TLS1CARD

LiftMaster Option Board for L4 L5

Works in conjunction with Logic 4 & Logic 5 to provide seven field-selectable modifications
Including six door traffic control options
A means to connect External Open & Close limits by using a selectable DIP switch
Controls both 24V & 110V traffic lights
Formally known as RDGRNCARD

Installation Manual

71-65WTC

LiftMaster Weatherproof Case (71-65WTBOX)

Optional weatherproof case suited for 412LMC 422LMC and 423LMC
Measurements of the interior: W=5.75" L=7" D=3"
Measurements of the exterior: W=7" L=10" H=3.5"

480LM

LiftMaster Alternate Mounting / Extension Kit for 3800 3900 8900W 8500 8500W

Enables the opener to be lowered due to obstructed areas and low ceilings
lowers the operator by 6" requires 1-1/2" above the door shaft
Installs quickly and easily
Same as 480LMB
Compatible with wall mount opener 98032 and 98022

Installation Manual Manuel d'Installation

SG10-24RG-LED

TriLite Stop & Go Traffic Signal 24V LED Yellow Housing **** Price by Quote ONLY

Red and Green LED traffic light
Approx. size: 11-1/2" High x 6-1/2" Wide x 4" Deep
24 volt DC input voltage only
Long lasting low power consumption
A simple reliable and cost-effective way to reduce accidents around the loading dock.
Available in two colors: safety yellow or black.

.......more details

Installation Instructions Instructions d'installation Wiring Diagram Schéma de connexion

8FT-BELT-LINEAR

Linear 8ft Belt Drive Rail for residential openers (HBT8C)

8ft belt-drive T-rail for LDO33 LDO50 LSO50 LCO75 & LDCO800 door operators
Fully-assembled & pre-tensioned
Compatible with Model CHCR-7/8 & CHCR-8 carriage house I-rail conversion kits

LD050

Linear 1/2 HP Deluxe Single Lamp Residential Garage Door Opener - Rails extra ***No Longer Available

Compatible with belt-drive or chain-drive T or I beam rails up to 10'
Rock solid performance
Diagnostic system indicates six possible trouble conditions
100-watt courtesy light (bulb not included)
Built-in MegaCode format receiver
All operator controls and indicators on one side

.......more details

Installation Manual User Manual Sell Sheet Remote compatibility chart

UCFL-1

Self-Aligning Cast Flange Bearing Football Style 1" Bore UCFL205-16

Grey cast iron painted.
Comes with 2x set-screws
Football style 2 bolt

RELAY021

Manaras Socket Base for Loop Detectors ZPD11

11-Pin base

CR-2149

Universal Photocells

Will work with all major brands of residential openers including: Chamberlain Liftmaster Craftsman Overhead Stanley Wayne Dalton Linear Raynor and Moore-O-Matic
The self programming feature allows you to simply hook up to the existing wiring
Suggested replacement for Stanley 49522 - must cut black wire

Installation Manual

12-000I

Secure Brands Keypad with Intercom Post Mount

Post mount with Intercom
RemotePro KP 26 bit wiegand output keypads
Available in three different mounting configurations: post single gang or flush.
All single gang RemotePro KP models are available with a silver aluminum faceplate.
A heavy duty metal keypad is used with all exterior models providing years of trouble free entry.
Post mount models feature a stainless steel faceplate in a heavy metal powder coated enclosure with nightlight.

.......more details

2598

Aluminum 5/16" Cable Eyelet

For use on Whiting dry freight and refer doors
Use with 1/8" stainless or galvanized cable

EL25G

LiftMaster Telephone Entry System Gray

Capable of accepting up to 2000 codes
4 assignable and programmable built-in relays
Mounting versatility and available in 3 colors: Gray Nickel or Silver

Installation Manual Sell Sheet

PED42

Pedestal Post 42" Gooseneck Pad Mount

Black powder coat finish
Faceplate with universal hole pattern to fit almost any access device
2" x 2" square post
Neck is bent with 6 in. center radius giving a tight professional look
Same as G559

M3-3313

Marantec 3-Button Transmitter 315 MHz 97245 ** Discontinued

Same as part # 65894 97245
Includes battery CR2032
Made in Germany

Instructions

3001-0

Signal Tube Treadle Hose Black Sold per foot

Applications: for gas stations and apartments
I.D. : 3/8"
Also known as Drive Over Hose.

10-30702

LiftMaster Chain Guard Top Cover Mfg Painted (K10-30702-2)

ARK

LiftMaster Auto Reconnect Trolley Kit

Installation Manual

1005-1-1/2-8'

Aluminum Bottom Retainer U-Shaped 8' Long

For door thickness 1-1/2"

41A6118

LiftMaster Travel Module (3800) *** No longer available To extent of inventory

Fits model 3800 confirmed with LiftMaster Tech support.

Programming Instructions

BOARD075E

Manaras Replacement Board Kit (No Monitoring)

Replacement kit that includes BOARD070E (control board) & BOARD066R (power board)
BOARD070E is for standard operators without the monitoring function
For all Manaras operators built after October 2010
On-board 390MHz radio receiver accepts 50 remote controls
For older models built before October 2010 use BOARD060 or replacement kit BOARD065

Replacement Chart Guide de remplacement

SMDRG

Linear 1-Ch Gate Receiver MegaCode 318 MHz *** No Longer Available

High gain superheterodyne receiver
High RFI immunity
Supplied with F-connector whip antenna and mounting bracket
Memory: storage for up to 40 MegaCode transmitters
Power: 24 VAC/VDC
Codes: 1000000+ (MegaCode format)

.......more details

Programming Instructions

MATDCBB3

LiftMaster Commercial DC Barrier Gate Operator Mega Arm Tower with Batteries ***Must include (2) x 29-NP712 battery***

24VDC barrier gate operator with battery backup
Continuous-duty motor with soft start/stop
Exceptional starting torque and continuous operation
Heavy-duty motor supports 6000 cycles per day
Operator speed of 2.5 seconds to open or close
Aluminum alloy chassis

.......more details

Installation Manual Mega Arm - Solar Power Sell Sheet

ED-1300

Devanco Citrus Degreaser & Cleaner 425g

This special blend of solvents is designed to quickly and effectively loosen and dissolve grease oil and dirt from metal parts
Leaves no residue
Pleasant citrus scent

Material Safety Data Sheet Fiche Signalétique

41C190

LiftMaster Transformer/Harness 120V/80VA/18V

02-401

Push Button Control Station 1-Button Surface Mount NEMA 1

Die-cast metal enclosure
START may be used as OPEN with all LiftMaster operators.
May be used as OPEN and CLOSE on all operators with type B2 control wiring

1005-1-3/4-12

Aluminum Bottom Retainer U-Shaped

For door thickness 1-3/4"

WG-305

Devanco White Lithium Grease

Provides long lasting lubrication and protection against rust and corrosion
Ideal for metal to metal applications
Sprays on thick providing a long-lasting protective coating that won't run off

Material Safety Data Sheet Fiche Signalétique

736

Fasteners Round Head Carriage Bolt 5/16-18 x 3/4" Gr 2 1000/Box

Full length thread
Max torque = 12

1005-1-3/4-10

Aluminum Bottom Retainer U-Shaped

For door thickness 1-3/4"

WKP250LM3

LiftMaster Wireless Keypad 250-Code ** Replaced by KPW250

Wireless access control keypad
250 code capacity - 4-digit codes
Wireless control of up to 4 doors or gates with additional GCUs
Post or surface mount standard
900MHz
Compatible with GCU and LiftMaster® 315MHz rolling code receivers

.......more details

Programming Instructions

MWRTA12B

Miller Edge Wireless Transmitter with Audible Alarm and 1 Channel Receiver

For 2-wire edges
Was previously MWRTA02A now has a new board making installation easier
Includes single channel receiver (MWR12A) and transmitter (MWTA12) with audible low battery alarm.
This feature that activates when the battery has only 25% of its life remaining indicating the battery should be replaced. The alarm sounds for 5 to 10 seconds at 1 to 2 minute intervals.
The receiver operates on either 12 or 24 volt AC/DC and provides N.O. or N.C. output.

Specification Sheet Installation Manual

29-NP712

Lead Acid Battery 12V 7A (K74-35388-1)

MK-00493

Reversing Contactor Telemecanique 24V Coil (MK-01179)

Same as MK-01179

41C3196

LiftMaster Antenna for Co-Axial Receiver

Wire antenna kit same as what is supplied in a 312 / 412 HMC

BK110/PR

Light Duty End Bearing Plate 3-3/8" with Bearing - EBF 338 Residential Sold as a Pair - LH/RH

With C16-32F bearing
Galvanized steel
3-3/8" shaft offset
Flange allows plate to be bolted to the wall for additional support
Same as part number 209

MGR-2

Linear 2-Channel MegaCode Gate Receiver 318 MHz *** To Extent of Inventory

Two Form ”A” (normally open) relays rated at 30 Volts AC/DC up to 5 Amps
Supplied with whip antenna three feet of coaxial cable and bulkhead connector
Memory: storage for up to 40 MegaCode transmitters
Power: 12 - 30 VAC or 10.5 - 30 VDC
Codes: 1000000+ (MegaCode format)
RF frequency: 318 MHz

.......more details

Installation Manual

15-50B18LGH

Sprocket 18 Teeth 1" Bore 1/4" Keyway

PRO-TB-5011-R

Micanan 1/2HP 115V 1P Trolley Operator with Brake - Contactor

Designed for use on commercial / industrial sectional overhead doors with standard lift tracks.
#410 roller chain on 1/2 HP models

RS1029

Roller 2" Steel 9" stem- WL 10 ball

Steel Roller Wheel Diameter: 2"
Working Length: 9.5" Overall Length: 10.5"
Box qty: 100 Box weight: 60 lbs (2-9-10 WL steel)

195LM

LiftMaster Ceiling Mount ***Discontinued***

Designed to fit most standard garages
Black powder-coated finish hides wires and cords for a cleaner look
Mounts parallel or perpendicular to rail
Adjustable height to fit most ceilings
Hangs 6.5 to 24 inches down from ceiling

Installation Manual Manuel d'Installation Sell Sheet Brochure

RESET003

Manaras Resettable Overload Fuse 6A 1 Phase

MH00013

Micanan Flange Bearing 3/4" ID x 1-3/8" OD

Pro-H requires 3 of these bearings

41C0279

LiftMaster Light Socket for Sec+ 2.0

New light socket designed to accept a broader range of compact fluorescent bulbs-CFL.
Compatible with LiftMaster garage door openers manufactured from 1993 to present.
New "insulated" design eliminates interference from CFL bulbs therefore better remote control range

TUBE_SHAFT_17FT

Hollow Shaft 1" x 17-0" Galvanized 16 gauge

882LMW

LiftMaster Multi-Function Control Panel Wi-Fi

Push button for garage door operation
Program remote controls Wi-Fi Garage Door Openers and MyQ® enabled accessories directly from the control panel
Light run-time is 4 1/2 minutes with adjustable light timer option
Lock feature designed to prevent operation of the door from portable remote controls
Compatible only with LiftMaster® Security+2.0™ and Wi-Fi garage door openers
Equivalent to Chamberlain's 41A7185

.......more details
