37408:Doorlec Reversing Contactor BF9 120VAC

MC271-2MON-RH-GY

Miller Edge MC271 2-Wire Monitored Right Hand Gray Includes End Flaps - Sold per Foot

Ideal for Cornell double angle bottom bar
Flexible and will conform to floor irregularities
Optimum size for 2+ inch thick surfaces
Custom manufactured to user specifications for color length and outlet location
5-inch end flaps create a complete seal and can be trimmed for custom fit
Sealed assembly impervious to dust and debris
UL 325 Recognized Component
Made in USA

MC271-2W-RH-BLK

Miller Edge MC271 2-Wire Non-Monitored Right Hand Black Includes End Flaps - Sold per Foot

Ideal for Cornell double angle bottom bar
Flexible and will conform to floor irregularities
Optimum size for 2+ inch thick surfaces
Custom manufactured to user specifications for color length and outlet location
5-inch end flaps create a complete seal and can be trimmed for custom fit
Sealed assembly impervious to dust and debris
UL 325 Recognized Component
Made in USA

CPT210-END-KIT-U

Miller Edge Universal End Kit for CPT210

Kit contains: 2) Caps (2) cages (1) wired plug (1) 10K plug (1) 8.2K plug (1) diode capacitor plug (1) non-mon. plug end plug (2) screws

ME210-C3

Miller Edge Black Rigid PVC Mounting Channel "L" Shape Sold by the Foot

Used on CPT-210 extrusion

RB-TX10C

Miller Edge RBand Monitored Wireless Edge Transmitter

RBand transmitter only
On board diagnostics allows for easy set up and troubleshooting.
Offers pulsed and normally open outputs.
Ideal for commercial door operators manufactured after 2010.
Bi-directional link improves immunity to RF interference.
Nema 4
2 year warranty
Operating temperature: -40C to 60C
916Mhz
Input: 10K monitored sensing edge
See also RB-P-K10C

RB-P-K10C

Miller Edge RBand Monitored Wireless Door Edge System

RBand is a monitored sensing edge transmitter/receiver system.
The receiver can be paired with up to three transmitters.
On board diagnosticsallows for easy set up and troubleshooting.
Offers pulsed and normally open outputs.
Ideal for commercial door operators manufactured after 2010.
Bi-directional link improves immunity to RF interference.
UL325
2 year warranty
Operating temperature: -40C to 60C
916Mhz

MWR22B

Miller Edge 2-Channel Wireless Edge Receiver RF 318 MHz

Power source: 12-24 volts AC/DC nominal Nominal 60 mA 140 mA activated
Output: N.O. N.C
Wire connections: Integral 18” wiring with #6 spade lugs
Antenna: Attached wire or F connector
LED Indicators: Power channel 1
Polycarbonate enclosure
Dimensions: 3-3/4”W x 4-13/16”H x 1-1/4”D (95 x 122 x 32 mm

CPT215-END-KIT-T3

Miller Edge End Kit for CPT215 Doide Capacitor (T3) Configuration

Kit contains: 2) Caps (2) cages (1) wired plug (1) diode capacitor plug (1) non-mon. plug (2) screws

CPT215-END-KIT-T2

Miller Edge End Kit for CPT215 10K Ohm Resistor (T2) Configuration

Kit contains: (2) Caps (2) cages (1) wired plug (1) 10K plug (1) non-mon. plug (2) screws
No glue is required

CPT215-PER-FOOT

Miller Edge Field Configurable Sensing Edge Cut-to-Length

For do-it-yourself edges on sectional or rolling doors.
Black extrusion flexible PVC conductive polymer Ends: Molded polymer
End plugs and mounting channel sold separately.
Sensing edge size: 1-5/8"H (41mm) x 1-11/16"W (42mm)
When combined with the ME123 mounting channel ideal for 2" thick surfaces
Minimum Length: 3ft
Billable Length: An edge that is 5'-2" is charged at 5' an edge 5'-2-1/2" is charged at 6'
Lead Wire 12 in. 22 gauge SJTO
Wire Outlet Location: Universal end plug
Electrical Maximum 24 volts AC/DC 1/2 amp

CPT-215-50

Miller Edge Field Configurable Sensing Edge 50 ft Roll

For do-it-yourself edges on sectional or rolling doors.
Black extrusion flexible PVC conductive polymer Ends: Molded polymer
End plugs and mounting channel sold separately.
Sensing edge size: 1-5/8"H (41mm) x 1-11/16"W (42mm)
When combined with the ME123 mounting channel ideal for 2" thick surfaces
Lead Wire 12 in. 22 gauge SJTO
Wire Outlet Location: Universal end plug
Electrical Maximum 24 volts AC/DC 1/2 amp

MWT12B

Miller Edge Transmitter Binary Nema 4 Enclosure

The MWT12 safety edge transmitter is designed to provide wireless signal transmission form the safety edge to the motor controls.
It is easily mounted and wired to the gate or door edge sensor. When the sensing edge comes into contact with an obstruction a closed circuit signal is created and is sent to the transmitter.
The transmitter relays the information to the receiver and the receiver passes the signal along to the operator motor.
The gate or door stops movement and will then reverse the direction of travel.
Comes standard with a NEMA 4 weather-proof enclosure. The enclosure can be easily mounted with the four mounting holes and screws provided
Response time: 70 milliseconds
Opertating temperature: 0°F to 130°F (-18°C to 55°C)
Operating frequency: 318Mhz
Maximum operating distance: 100ft
Coding: Selectable 9 pole 2 position DIP switch
Power Source: (2) 1.5 volts AA alkaline batteries
Input/Output: Input: 2-wire N.O. sensing edge
Repl.: MWT12

Installation Instructions MWT12B Spec Sheet MWT12B FAQ MWT12B

MWTA12B

Miller Edge Transmitter with Low Battery Alarm Small

The transmitter comes standard with a NEMA 4 weather-proof enclosure
Compact design that allow for easy troubleshooting.
The transmitter has an audible alarm that activates when the battery has 25% of its life remaining
Easy to configure · Non-monitored system ideal for operators manufactured prior to: · Doors: August 2010 · Gates: January 2016 · NEMA 4 transmitter built to endure rugged environments
Power Source: (2) 1.5 volts AA lithium batteries
Input: 2-wire N.O. sensing edge
Demensions: 1-13/16”W x 5-3/4”H x 2-1/8”D (46 x 146 x 54 mm)
Enclosure: Polycarbonate
Low Battery Alert: Alarm; 80-95 dB at 2’

Installation manual Spec sheet

ME120-Y-4E-P/FT

Miller Edge Sensing Edge Yellow 4-Wire Monitored End Outlet Sold per Foot

Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
Touch sensitive signaling
Temperature range: -30F to 155F
Lead wire: 18 gauge 2ft length
Sensitivity: nominal 4 PSI
2 wire NO configuration
Vertical or horizontal mount
ANSI/UL325 recognized component
Mounting channel sold separately
One year warranty

MT21-YELLOW-LH

Miller Edge 2-Wire Pressure Sensitive Edge Yellow Left Hand Outlet Sold per Foot

��Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty

MT21-2M-YELLOW-E

Miller Edge 2-Wire Monitored Pressure Sensitive Edge Yellow End Outlet Sold per Foot

��Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty

MT21-2M-YELLOW-R

Miller Edge 2-Wire Monitored Pressure Sensitive Edge Yellow Right Hand Outlet Sold per Foot

��Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty

MGR20-B-2U-M-P/FT

Miller Edge Sensing Edge Round Black 2-Wire Universal Outlet Monitored Sold Per Foot

��Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty •Monitored edge - pls specify the operator edge is connecting to •Maximum length is 10ft (over 8ft requires LTL shipment at additional cost)

AW14K500-18-RF

Miller Edge Air Wave Edge System Trans/Recvr 18ft Non-Monitored

AW14-RF MRF-01 RAH-500 (18') P50 P-50H 218-27-18
AW14-RF-K10 end plug connector plug 1/2”-18 ft. hose

MC22-2WIRE-RH-BLK

Miller Edge MC22 2-Wire Non-Monitored Right Hand Black Includes Funny Flaps - Sold per Foot

��Electromechanical sensing edge for use on Cornell doors. •The MC22 is manufactured to exact specifications. •The MC22 is completely flexible and will contour to curved surfaces. •Touch sensitive signaling allows immediate reversing or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Vertical or horizontal mount •One year warranty

Worksheet

RLC-K36

Miller Edge Light Curtain Non- Monitored 3ft NO/NC

Light curtain made up of a series of thru-beam photo eyes designed to provide a dense barrier of protection for motorized or high speed doors.
Ideal for environments that require expanded protection for protruding parts that may not be detected by standard single-beam photo eyes mounted 6" above the floor.
Ideal for pre-2010 installations not requiring a monitored solution.
Ability to span up to 32' wide
Universal mounting brackets included
IP67 waterproof housing
Operating temperature: -40F to 140F
UL325 recognized component
2 year warranty

MILLER-LEAD-WIRE

Miller Edge Up-Charge for Custom Length Lead Wire Sold by the Foot

Up charge for extra lead wire

ME120-B-4E-P/FT

Miller Edge Sensing Edge Black 4-Wire Monitored End Outlet Sold per Foot

Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
Touch sensitive signaling
Temperature range: -30F to 155F
Lead wire: 18 gauge 2ft length
Sensitivity: nominal 4 PSI
2 wire NO configuration
Vertical or horizontal mount
ANSI/UL325 recognized component
Mounting channel sold separately
One year warranty

RG-K-P

Miller Edge Reflecti-Guard Pulsed Photo Eye Monitored 30ft Range

Monitored retro-reflective technology
Includes: (1) wired emitter/receiver with integrated mounting bracket (1) reflector (1) reflector bracket
30 ft. range
Pulsed and relay models
Enhanced sunlight immunity
Impact resistant for rugged environments
Easy installation and minimal maintenance with reflector
Time-saving installation with alignment LED
Universal adjustable mounting brackets
Vertical or horizontal mounting surface
UL 325 Recognized Component

PS-20A

Miller Edge Pneumatic Air Switch in ABS Enclosure

Pneumatic switch offering a reliable low cost alternative to a standard electric sensing adge.
When attached to a hose inserted into the existing weather stripping the PS-20A acts as an effective sensing edge on doors up to 18ft in length.
Applications: rolling doors sectional doors and mass transit.
Electrical configuration: 3-wire SPDT
Temperature range: -20F to 158F
Max pressure: 20 PSI
Weather resistant casing and weather tight strain relief
One year warranty

MG020-Y-2E-P/FT

Miller Edge Sensing Edge Yellow 2-Wire End Outlet Sold per Foot

Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
Touch sensitive signaling
Temperature range: -30F to 155F
Lead wire: 18 gauge 2ft length
Sensitivity: nominal 4 PSI
2 wire NO configuration
Vertical or horizontal mount
ANSI/UL325 recognized component
Mounting channel sold separately
One year warranty

ME112-C4

Miller Edge Clima-Guard U-Shaped PVC Mounting Channel Sold by the Foot

CG-4W-MON-BLK-RH

Miller Edge Clima-Guard 4-Wire Monitored Black Right Hand Outlet Sold by the Foot

Clima-Guard functions exactly like a pressure sensitive electric edge but with an added layer of protection.
The protective loop seal conforms to irregularities in the floor and helps prevent air infiltration and serves as a weather barrier.
ClimaGuard is made up of an ME112 sensing edge paired with a PVC loop seal that comes with a double slot mounting channel.
Electrical Configuration: Normally open
this edge comes with the channel

ME111-4WIRE-M-RH

Miller Edge 4-Wire Monitored Black Right Hand Outlet 7/8" wide x 1-1/2" high Sold by the Foot

Slide in style edge for barrier gate and counter shutter application.
Touch sensitive signaling allows for immediate stopping/reversing of motion depending on application. •Temperature Range: -30F to 155F
Lead wire: AWM 22 gauge 2ft length
Sensitivity: nominal 6-8 PSI
Vertical or horizontal mount
ANSI/UL325 recognized component
Mounting channel sold seperately
One year warranty

Worksheet Installation manual Sell sheet

ME110-M-2W-BLK-E

Miller Edge Monitored 2-Wire Black End Outlet 7/8" wide x 3/4" high Sold by the Foot

Electromechanical slide in edge for counter shutters rolling doors and barrier arm applications.
Touch sensitive signaling that allows for immediate stopping and reversing of motion.
Temperature range -30F to 155F
Lead wire: 22 gauge universal
Sensitivity: nominal 6-8 PSI
2 wire NO configuration
Vertical or horizontal mount
ANSI/UL325 recognized component
Mounting channel sold seperately
One year warranty

Worksheet

ME110-C3

Miller Edge Black Rigid PVC Mounting Channel Double-Sided Tape Sold by the Foot

7/8" length

ME123-2M-BLK-RH-T3

Miller Edge Black RH 2-Wire Monitored T3 2" wide x 1-1/2" high Sold by the Foot

Electromechanical slide in edge for sectional doors and sliding gates.
Touch sensitive singaling allows for immediate stopping and reversing of motion
Temperature range: -30F to 155F
Lead wire: 22 gauge universal
Sensitivity: nominal 6-8 PSI
2 wire NO configuration
Vertical or horizontal mount
ANSI/UL325 recognized component
One year warranty
T3 = Diode capacitor
Will fit in 1005-1-3/4" and 1005-2" retainer

Worksheet Installation manual Sell sheet

MAW123-YEL-RH

Miller Edge Air-Wave Edge Yellow Sold per Foot

This pressure sensitive air-wave edge can be adapted to suit a wide variety of applications.
When touch activated the MAW123 sends an immediate pulse of air through the extrusion to an air-wave switch which sends a signal to controls to stop and/or reverse operations.
It has been designed to fit most doors with double track bottom retainers.
With appropriate mounting channel this edge will fit nearly all doors from 11/2" to 2" thick.
The MAW123 is resistant to flame water and most common greases and oils.

ME123-2M-BLK-RH

Miller Edge Black RH 2-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

Electromechanical slide in edge for sectional doors and sliding gates.
Touch sensitive singaling allows for immediate stopping and reversing of motion
Temperature range: -30F to 155F
Lead wire: 22 gauge universal
Sensitivity: nominal 6-8 PSI
2 wire NO configuration
Vertical or horizontal mount
ANSI/UL325 recognized component
One year warranty
Comes standard with T2 10K resistor unless otherwise stated
Will fit in 1005-1-3/4" and 1005-2" retainer

Worksheet Installation manual Sell sheet

RLC-K72

Miller Edge Light Curtain Non- Monitored 6ft

Light curtain made up of a series of thru-beam photo eyes designed to provide a dense barrier of protection for motorized or high speed doors.
Ideal for environments that require expanded protection for protruding parts that may not be detected by standard single-beam photo eyes mounted 6" above the floor.
Ideal for pre-2010 installations not requiring a monitored solution.
Ability to span up to 32' wide
Universal mounting brackets included
IP67 waterproof housing
Operating temperature: -40F to 140F
UL325 recognized component
2 year warranty

Installation manual sell sheet

CPT-223-PER-FT

Miller Edge Bulk Extrusion Sold per Foot

For DIY quick fixes to repair or replace sensing edges for sectional and rolling steel doors measuring 1-1/2" to 2" thick with a mounting channel.
Sensivity: 15lbs max activation
Lead wire 18"-22 gauge unversal
Wire configuration: N.O.
Electrical interface: sealed module- provides seamless connection to logic or relay type operators
ANSI/UL325 recognized component

MEL-II-TX10

Miller Edge Monitored Edge Link-II Transmitter

Miller Edge Monitored Edge Link II TRANSMITTER ONLY
Monitors the presence and function of any 10K (T2) monitored sensing edge
Provides a monitored wireless signal transmission from the sensor to the operator controls
Improved immunity to RF interference with 916 MHz operating frequency
Eliminates visible coil cords and retracting reels
Saves installation time
Aesthetically pleasing appearance free of dangling wires
Standard AA lithium batteries simplify replacement and withstand extreme temperatures
Dimensions (TX): 1.75"W x 4.62"H x 1.75"D

ME123-2M-BLK-U

Miller Edge Black Universal 2 -Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

Electromechanical slide in edge for sectional doors and sliding gates.
Touch sensitive singaling allows for immediate stopping and reversing of motion
Temperature range: -30F to 155F
Lead wire: 22 gauge universal
Sensitivity: nominal 6-8 PSI
2 wire NO configuration
Vertical or horizontal mount
ANSI/UL325 recognized component
One year warranty
Comes standard with T2 10K resistor unless otherwise stated
Will fit in 1005-1-3/4" and 1005-2" retainer

Worksheet Installation manual Sell sheet

ME113-C7

Miller Edge PVC Mounting Channel Flat Sold by the Foot

MEFF-PAIR

Miller Edge Funny Flaps for MC22 Sold as a Pair

Funny Flaps for use with the MC22 Sensing Edge and are a great fit for an application where extra sensitivity is needed
They're necessary to fill the gap between the edge and guide within the sensing edge system and their flexible durable construction offers an alternative to more rigid standard sensing edge setups.

MC22-2WIRE-LH-G

Miller Edge MC22 2-Wire Non-Monitored Left Hand Gray Includes Funny Flaps - Sold per Foot

��Electromechanical sensing edge for use on Cornell doors. •The MC22 is manufactured to exact specifications. •The MC22 is completely flexible and will contour to curved surfaces. •Touch sensitive signaling allows immediate reversing or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Vertical or horizontal mount •One year warranty

Worksheet

MIRF-T2

Miller Edge Patriot 2 Photo Eye Non-Monitored 30ft Non-Contact

Attaches directly to a Sectional door.
The photo eyes travel below the door during the closing cycle.
Unlike traditional static mount photo eyes; Patriot travels with the door sensing obstructions prior to contact.
The Patriot2 non-contact system consists of thru beam photo optics.
Emitting and receiving eyes mount into a rigid steel spring loaded retracting housing.
The housings attach to the bottom section of the door and extend below the leading edge of the door providing an invisible infrared light beam of protection.
If the beam is blocked the control unit signals the door operator to stop and/or reverse.
It is also available in fail safe wiring configuration (MIRF-T2).
Kit includes: Sender Receiver Telescopic Leg Kit 15 Feet Coil Cord and Junction Box with Cover

MGR20-Y-2R-04

Miller Edge Sensing Edge Round Yellow 2-Wire Right Hand Outlet 4ft Long

��Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty

MG020-B-4E-P/FT

Miller Edge Sensing Edge Black 4-Wire Monitored End Outlet Sold per Foot

Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
Touch sensitive signaling
Temperature range: -30F to 155F
Lead wire: 18 gauge 2ft length
Sensitivity: nominal 4 PSI
2 wire NO configuration
Vertical or horizontal mount
ANSI/UL325 recognized component
Mounting channel sold separately
One year warranty

MGR20-B-2U-PER-FT

Miller Edge Sensing Edge Round Black 2-Wire Universal Outlet Sold Per Foot

��Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
Non-monitored edge
Maximum length is 10ft (over 8ft requires LTL shipment at additional cost)

MGR20-Y-2U-PER-FT

Miller Edge Sensing Edge Round Yellow 2-Wire Universal Outlet Sold Per Foot

��Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
Non-monitored edge
Maximum length is 10ft (over 8ft requires LTL shipment at additional cost)

ME117-M-BLK-U

Miller Edge 4-Wire Monitored Black Universal Outlet Sold by the Foot

Electromechanical slide in edge for 1" to 2" sectional doors.
Touch sensitive signaling allows for immediate stopping or reversing of motion. The ME117 is resistant to water flame and most common greases and oils.
Temperature range: -30F to 155F
Lead wire: 22 gauge universal
Sensitivity: nominal 6-8 PSI
2 wire NO configuration
Vertical or horizontal mount
ANSI/UL325 recognized component
One year warranty
May also be used in scissor lift conveyor and press applications.

Installation manual Sell sheet

JB-02P-W

Miller Edge Junction Box Nema 4

For use with commercial door operators and CPT sensing edges from Miller Edge
Waterproof
Accommodates wire .181 to .312

Installation instructions

JB-02

Miller Edge Junction Box Metal

For commercial overhead doors that use coil cords or retracting reels
Standard metal junction box with cover
Includes 1 x 90-degree connector 1 straight connector
Includes strain relief + 2 wire nuts + pop-out holes
For single-angle bottom bar of rolling steel door
Also compatible with sectional door

ME120-BLK-2WIRE-E

Miller Edge Black 2-Wire End Outlet Sold per Foot

Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
Touch sensitive signaling
Temperature range: -30F to 155F
Lead wire: 18 gauge 2ft length
Sensitivity: nominal 4 PSI
2 wire NO configuration
Vertical or horizontal mount
ANSI/UL325 recognized component
Mounting channel sold separately
One year warranty


User Name:
Password:
Remember Me:

	Forgot your password
Request a Login

Doorlec Reversing Contactor BF9 120VAC

DETAILS
