L956W:LiftMaster Wireless Multi-Function Control Panel Security+ 3.0

LiftMaster Wireless Multi-Function Control Panel Security+ 3.0

Item #: L956W

Manufacturer: Chamberlain, LiftMaster

List price: $48.38

Manuals & Brochures:
Installation Manual, Compatibility Chart 2025 , Manuel d'Installation , Comparison Chart 2025,

DETAILS

Wireless control panel can be installed almost anywhere in the garage.
Includes a large push bar for garage door opener operation and a light control button.
Built-in learn button enables fast & easy programming of remotes keypads myQ® accessories and Wi-Fi garage door openers.
Compatible only with LiftMaster Security+ 3.0™ garage door openers.
No wiring required. Powered by CR2032 battery (included).
Warranty: 1 Year

Other Search Results Containing "Doorlec"

20111

Doorlec Cam Retainer Plate Springs *** Replaced by 26117

Works on GH/GHX

26130

Doorlec Hoist Shaft Threaded 5/8" x 12" GH/GHX

Works on GH/GHX

28412

Doorlec Flange Bearing 5/8" Bore Oilite Bushing

Works on GH/GHX

37520

Doorlec DC-2000 Electronic Circuit Board UL325 Requires Monitored Photocells

Works in all Doorlec model openers except R-99
Input power to board is 120V
24V DC available on terminals 9 & 11
Accessory power on terminals 1 & 11
1 = Stop. 2 = Com. 3 = Open 4 = Close
Can be adjusted for constant pressure

27121-600V

Doorlec Electric Motor 1-1/2 HP 600V 3PH DC223C

27121-480V

Doorlec Electric Motor 1-1/2 HP 480V 3PH DC223C

14128

Doorlec Hoist Disconnect Lever GH/GHX

31376-2

Doorlec Sprocket 60B65 2" Bore

GHX-383-3/4HP-RH

Doorlec Explosion Proof Gear Head 3/4 HP 208V 3PH ECB Right Hand

Nema 7/9 control box
Electrical connections from motor to control box consists of hazardous location certified fittings and NEMA 7/9 O/C/S push-button station

27118-600V

Doorlec Electric Motor TEFC 2HP 600V 3PH DC224C

Frame size is 56C 1725 RPM for worm-gear reducer driven models

42685

Doorlec SGP Operator Cabinet Only

GHX-311-3/4-LH

Doorlec Explosion Proof Gear Head 3/4 HP 120V 1PH ECB Left Hand

Nema 7/9 control box
Electrical connections from motor to control box consists of hazardous location certified fittings
NEMA 7/9 O/C/S push-button station included

GHX-311-3/4HP-RH

Doorlec Explosion Proof Gear Head 3/4 HP 120V 1PH ECB Right Hand

Nema 7/9 control box
Electrical connections from motor to control box consists of hazardous location certified fittings
NEMA 7/9 O/C/S push-button station included

31120-112-3/8

Doorlec Sprocket 50B36 1-1/2" Bore 3/8" KW

36 tooth sprocket

26142

Doorlec Cam Shaft Threaded 5/8" x 7-1/4" w/Sprocket GHX

Explosion Proof rotary shaft 1.59cm x 18.4cm

GHW-311-3/4

Doorlec Ind. Duty Jackshaft Carwash Op. 3/4 HP 115V 1P with ECB

With DC2000 logic board
Worm-Gear Jackshaft type Industrial operator NEMA 4/12

GHX-311-1-RH

Doorlec Explosion Proof Gear Head 1 HP 120V 1PH ECB Right Hand

Nema 7/9 control box
Electrical connections from motor to control box consists of hazardous location certified fittings
NEMA 7/9 O/C/S push-button station included

24040

Doorlec Roller Chain #40 Sold per Ft

19045

Doorlec VBelt 4L360

41011

Doorlec Brake Release Cable

Used on GH

50181

Doorlec Brake Assembly 230/208V W/Double Pulley

Complete brake assembly

LJH-353-1-RH

Doorlec 1 HP 575V 3PH Jackshaft Operator

Model LJH lasts an average of 10 million cycles
Available with ⅓ HP to 1 HP single-phase or three-phase motor and is equipped with self-adjusting solenoid brake
LJH installation is universal regardless of side (left or right)
Speed is approximately 1.4 feet per second or about 0.3 meters per second
Comes equipped with a manual chain hoist

50308

Doorlec Cam Shaft Assembly Comes With Bearings

Fits LJ LJH SGO

27120-575V

Doorlec Electric Motor 1/2HP 575V 3PH DC221

12118

Doorlec Commercial Aluminum Sliding Carriage

Works on Doorlec trolley operators

27209

Doorlec Electric Motor TEFC 3HP 208/480/575V 3-Phase DC333C

Frame size is 56C

31226

Doorlec Sprocket 41B48-1" shaft

36310

Doorlec Flicker Relay OFF/ON 120V AC

31114

Doorlec Sprocket 410B09 5/8" Bore 3/16" Keyway

9 tooth sprocket

26141-NEW

Doorlec Cam Shaft 11-1/4" x 5/8" (28.575 x 1.59cm)

Fits the new larger box

ETBH-311-3/4HP

Doorlec 3/4 HP 115V Trolley Door Opener with solenoid brake

Trolley model heavy-duty door operator designed to provide smooth dependable operation of sectional overhead type doors.

20102

Doorlec Reversing Arm Spring

29140

Doorlec Transformer 230V pr 120V sec 50VA

230V primary 120V secondary 50VA

29201

Doorlec Transformer 460V pr 120V sec 35VA

460V prImary 120V secondary 35VA

LJH-353-1/2

Doorlec 1/2 HP 575V 3PH Jackshaft Operator

Heavy duty industrial type control station open close stop 24V. control circuit
Universal mounting right or left
Floor level disconnect device electrical and mechanical
Emergency chain hoist operation on LJH model only
Colour code wiring diagrams
Rotary type limit switches readily adjustable in both directions
Self adjusting solenoid brake
Friction safety clutch
Motor removable without disturbing limit adjustment or chain hoist operation
Heavy duty RC-41 roller chain drive throughout
All three phase motors totally enclosed fan cool
Overload and under voltage protection

22019

Doorlec Push Button Contact Block N/O

GUSSET-MOUNT

Doorlec Gusset Mount Plate Up-Charge (L Bracket) GH

Mounting plate for GH op

GHW-383-1HP-RH

Doorlec Industrial Gear Head Door Operator 1 HP 208V 3P with ECB and Nema4 modification

Extra heavy-duty industrial-type electric door operator for damp environments.
Worm gear reducer 40:1 ratio
#50 roller chain and sprockets from operator shaft to door shaft. (#60 chain optional)
Door speed: 7 inches per second (approx.)
Adjustable torque limiter (also called friction clutch)
Rotary type limit switches
3-Btn control (N4). momentary-contact type for Open Close Stop
Solenoid disk brake solenoid inside waterproof control box
Sideroom required: 24 inch minimum
Maximum Door weight: 6800 LBS

50018

Doorlec Photo Switch Polarized Explosion Proof Reflective w/Round Reflector

Class 1 Div 1 Groupes CDEFG explosion proof Certified CSA

GHX-353-1.5HP-R

Doorlec Explosion Proof Gear Head 1-1/2 HP 575V 3PH ECB Right Hand

Nema 7/9 control box
Electrical connections from motor to control box consists of hazardous location certified fittings
NEMA 7/9 O/C/S push-button station included

GHX-353-1HP-RH

Doorlec Explosion Proof Gear Head 1 HP 575V 3PH ECB Right Hand

Nema 7/9 control box
Electrical connections from motor to control box consists of hazardous location certified fittings
NEMA 7/9 O/C/S push-button station included

31373-114

Doorlec Sprocket 60B36 1-1/4" Bore

31369-114

Doorlec Sprocket 60B12 1-1/4" Bore

31111-114

Doorlec Sprocket 50B70 1-14" Bore KW/SS

GHW-353-3HP-RH

Doorlec Ind. Duty Jackshaft Carwash Op. 3 HP 575V 3P Right Hand *** By Quote Only

With DC2000 logic board
Worm-Gear Jackshaft type Industrial operator NEMA 4/12

LDJ-CAP-48MFD

Doorlec Run Capacitor for LDJ RCR50-370

370VAC/B 50 uf 50/60 Hz
CSC run capacitor

50695

Doorlec Clutch & Pulley Assembly for EHJX

Includes shaft and bearings

EHJX-353-1

Doorlec Industrial Jackshaft Op. Explosion Proof 1 HP 575V-3Ph ** Price on Request

Explosion proof NEMA 7/9 Heavy-Duty Industrial Operator
DC-2000 logic with adjustable Timer To Close Delay On Reverse.
Solenoid Brake prevents coasting and secures the door when closed
Explosion-proof (sealed) continuous-duty electric motor with overload protection
Automatic Friction Clutch protects the door and operator
Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
#50 drive chain 5L350 v-belt
Universal design allows installation of operator on either side of the door
Floor Level Disconnect and Manual Chain hoist in case of power failure
Operating speed approx 8-10" per second
Includes 1" chain spreader Part # 50535
Inlcudes explosion-proof open/stop/close wall control
2 year Warranty

15470

Doorlec Heater Strip 250 W 120 V

15055

Doorlec Electronic Thermostat 330V B1 Metal
