Miller Edge Transmitter RF in Nema 4 Enclosure *** To Extent of Inventory

Item #: MWT12

Manufacturer: Miller Edge

Discontinued:

MWT12 no longer available, replaced by the MWT12B.

Lists of Replacement product for the discontinued product(MWT12).

MWT12B

Miller Edge Transmitter Binary Nema 4 Enclosure

The MWT12 safety edge transmitter is designed to provide wireless signal transmission form the safety edge to the motor controls.
It is easily mounted and wired to the gate or door edge sensor. When the sensing edge comes into contact with an obstruction a closed circuit signal is created and is sent to the transmitter.
The transmitter relays the information to the receiver and the receiver passes the signal along to the operator motor.
The gate or door stops movement and will then reverse the direction of travel.
Comes standard with a NEMA 4 weather-proof enclosure. The enclosure can be easily mounted with the four mounting holes and screws provided
Response time: 70 milliseconds
Opertating temperature: 0®®F to 130®®F (-18®®C to 55®®C)
Operating frequency: 318Mhz
Maximum operating distance: 100ft
Coding: Selectable 9 pole 2 position DIP switch
Power Source: (2) 1.5 volts AA alkaline batteries
Input/Output: Input: 2-wire N.O. sensing edge
Repl.: MWT12
