41ACOM12001

LiftMaster Capacitor 32UF 230V **DISCONTINUED

CPS3-N4

LiftMaster Option Card with CPS-UN4 Eyes for applications requiring 2 sets of photocells

For applications requiring two sets of photoeyes in a damp location
Range up to 45ft water dust and corrosion proof eyes (Nema 4x rating)
Works with Logic 3 4 5 Commercial Operators
Includes Durable steel brackets - floor or track mounting
Kit Inludes one set of CPS-UN4 and one CPS3 card ( CPSIII )

3-32-1

Low Headroom Top Bracket 2" Residential 1 pc

For residential door with 2" track

5735.96

Whiting Bottom Seal Grey 96"

For Dry Freight and Truss Doors

226-9312

Lithium AA 1.5V Battery

Used in IG2 photo eyes

BK021/PR-BOLT

Commercial 3" Safety Bottom Bracket with Bolt Sold as a Pair

Maximum cable diameter: 1/4"
Maximum door weight: 1650 lbs Zinc
Plated Steel
Sold as a pair

Installation Manual Specification Sheet

37516S

Genie Belt only for 8ft Door

Replacement belt only for 8ft door
Fits Genie model Destiny 1200

K75-10259

LiftMaster Track Spacer Assembly

Standard duty trolley operator part

MD-00006

Sprocket 41B10 x 3/4" NO KW 2SS 1/4

LYNX-6000-BOARD

Lynx 6000 Commercial Logic Board

Replacement logic board for Lynx commercial operators built from 2002 through 2005
Will not work for the ALDJ Model (Light Duty) •

Basic Operation Manual

TUBE_SHAFT_12FT

Hollow Shaft 1" x 12'-10" Galvanized 16 gauge

When ordering order one foot longer that actual door width

3950-41DS

LiftMaster Dead-Shaft Sprocket Kit for 3950

Used on doors without live shafts
Same as 41A7280
Includes #41 chain sprocket

Sell sheet

NIR-HD

EMX Industries NIR Hood Cover Steel

The hood keeps rain and other debris from distorting or blocking the photo beam.
It also helps to keep the sun from glaring off the reflector and disturbing the beam's reflection.
Replaces the mounting bracket that comes with the sensor.
Comes with Hood two sets of nuts and bolts and a plug

4X20PO50

Devanco Loop 4' x 20' pave-over 50' lead-in

Ideal for use on with gravel driveways or surfaces that are to be asphalted
Features a twisted lead-in to reduce the chances of interference and false detections.
Direct burial loops should be buried approximately 6" deep

Installation instructions Instructions d'installation Spec Sheet Brochure Loop Placement Guide Guide de positionnement des boucles

ME123-M-BLK-LH

Miller Edge Black LH 4-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

Electromechanical slide in edge for sectional doors and sliding gates.
Touch sensitive singaling allows for immediate stopping and reversing of motion
Temperature range: -30F to 155F
Lead wire: 22 gauge universal
Sensitivity: nominal 6-8 PSI
2 wire NO configuration

.......more details

Worksheet Installation manual Sell sheet

MCJH-453-CONT-R

Lynx Heavy-Duty Jackshaft 3/4 Hp 575V 3 Ph Contactor Right Hand ** Replaced by CDJH

Sell Sheet

PULLEY007

Manaras Clutch Pulley 8" x 1" bore

1003-3-DF-200FT

Bottom U-Rubber 3" Dual Fin Black 200' Long

200ft spool of vinyl insert.
Dual fin

CONTACTOR041

Reversing Contactor 1 Ph-9A-24VAC

ZT37028235

Firestar Shutter 540 Galv with Lock & Key

7119405

FAAC 400 Plug for End Cap

MU22-2WIRE-E-Y

Miller Edge MU22 2-Wire End Yellow - Sold per Foot

��Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty

Worksheet Installation manual Sell sheet

T-833-H

FL-Heddolf 3-btn Transmitter 311 MHz ** this model is discontinued

Open/Close up to 3 doors or Open/Close/Stop one door
Heddolf-Keystone 3 button transmitter 311mhz
8 3-Position dip switch format
9V battery and metal clip included
Compatible with Allstar 3 button T-833
Same as P220-3K

.......more details

PRO-TB-7523-U

Micanan 3/4HP 230V 3P Trolley Operator with Brake N1 Eyes Monitored ECB

Designed for use on commercial / industrial sectional overhead doors with standard lift tracks.
#41 roller chain on 3/4 HP models
Monitored board

MD00045

Micanan Spur Gear 12B72-1

OSH-6213-ECB-LH

Manaras Opera-SH 3/4 HP 240V 1Ph with Electronic Circuit Board Left Hand *** To Extent of Inventory

An ultra high-end heavy-duty V-belt drive industrial jackshaft operator
For use on Standard High and Vertical Lift sectional doors
Can also be used on Rolling doors and Grilles
Comes with a chain hoist for manual operation and a floor level engaging device
Clearence: side room required 16"
25 cycles per day > 100 cycles per day

.......more details

Installation manual Sell sheet

DS75

Light Commercial Non-Insulated Rollup Door with Exterior Curtain Lock ** Price by Quote Only

Mini Storage door non insulated with exterior curtain lock
Custom ordered to exact size
Available colors: Wayne Dalton White Glossy White Mist White Black Contemporary Brown Bronze Buckskin Desert Tan Polar Blue Pacific Blue Royal Blue Teal Bright Green Hunter Green Fern Green Sea Green Cedar Red Violet Red Patriot Red Silhouette Grey Yellow Maroon Harvest Orange Sunset Orange Tangerine

Sell Sheet Drawing

HTUS

Stainless Steel Garage Door Top Roller Bracket 12-Gauge Single Slot

Manufactured with 12ga. Rust-Resistant 304 Stainless Steel
Universal Design
Adjustable from 2"-3-1/2"
Fits Most Overhead Sectional Doors
Priced Per Each

MX00140-NEW

Micanan Brake Assembly for PRO-TB/APTB NO Solenoid - New Model (SBR-N1-00-TTBPAPT)

IRB-MON

EMX Industries Nema 4 Through-Beam Photocells with Gold Hoods New UL325-2018 *** No Longer Available

Type B1 non-contact sensor
UL325-2018 compliant
Lens-less design
Simple 2-wire connection
Relay contacts available
NEMA 4X enclosure

.......more details

Installation Manual Sell Sheet

MOTOR403

Manaras Electric Motor 1/2HP 120V 1PH

Instant reverse
Medium-duty 1500 rpm
For OMJ/OMH

ST-CLEAR-TUBE

Soft Touch Clear Tubing Sold per Foot

ST-GLUE

Soft Touch Glue 1oz/25g

For use with Soft Touch Profile
1 oz

ME111-R

Miller Edge Black Right Hand Outlet 7/8" wide x 1-1/2" high Sold by the Foot

Slide in style edge for barrier gate and counter shutter application.
Touch sensitive signaling allows for immediate stopping/reversing of motion depending on application. •Temperature Range: -30F to 155F
Lead wire: AWM 22 gauge 2ft length
Sensitivity: nominal 6-8 PSI
Vertical or horizontal mount
ANSI/UL325 recognized component

.......more details

Installation Manual Worksheet Sell Sheet

29202

Doorlec Transformer 550Vpr 120V sec. 35VA

CLUTCH-ASY-MCJH

Lynx Complete Clutch Shaft Assembly for MCJH Operators 5/8" x 12-1/2"

1005-1-1/2-10'

Aluminum Bottom Retainer U-Shaped 10' Long

For door thickness 1-1/2"

MALEDCW

LiftMaster Counterweight for 17ft LED Arm

For use with MALED17 17 ft. LED Arm for MA/MAT

MDT-4B

Linear 5-Channel Visor Transmitter MegaCode Block Coded 318 MHz

Compatible with all Linear access receivers and controllers
Superior transmission range
Unique ”Extra” top button
High visibility operate LED
Visor clip included
Sold in lots of 10

.......more details

Programming instructions

28773A

Genie Idler Pulley for Belt Drive

Fits PMX500-I B/C Belt & Chain drive model
Front Pulley for belt channel applications only.
Compatible with the Ovehead Door Legacy BELT DRIVE (model #696 and #496) and Phantom (model #777) garage door opener
Part Numbers: 28773 28773AS 28773S 38773A

H105L5-RH

LiftMaster Ind. Duty Hoist Op. 1 HP 575 VAC 3 Ph Logic 5 Right Hand W/Brake ***No Longer Available

Includes CPS-U
H-style operators include a floor level chain hoist to ease manual operation in an emergency or power outage.
The operators are typically mounted to the wall when used with larger sectional overhead doors with vertical or high lift and mounted to the wall or the front of the hood when used with rolling doors and grilles.
H operators are attached to the door jackshaft to indirectly drive the door. Connectivity
MyQ® Technology enables you to securely monitor and control your facility operator and lights with your smartphone tablet or computer for greater peace of mind.
Alerts can be received as email or pop-up (push) notifications on a mobile device ensuring the status of your commercial door.

.......more details

Installation Manual Manuel d'installation Sell sheet Brochure

MG00021

Micanan Flat Washer 7/8" ID x 1-1/8" OD

11-10705

LiftMaster Output Shaft MH

15-19478

LiftMaster Sprocket Assembly

For model H (2005-present)
48B32T with hub

MOUNTSHAFT010

Manaras Hoist Shaft Kit for MJH (pre-1998)

Drawing

R5996

Shaft Collar 1" Split Black Oxide

9150000620

3/32" Sleeve ONLY 100/pkg

Sleeves only 100 per pack

DXT-21

Linear 2-Btn 1-Channel Handheld Transmitter 315 MHz *** No Longer Available

A battery powered portable transmitter designed for use with Linear’s DX Format receivers.
Each transmitter can be used in a limitless number of wireless remote control applications.
Pressing a button on the transmitter sends a digitally coded wireless signal to its companion receiver
The digital DX code format features over a million possible codes.
The DX transmitters are precoded at the factory to unique codes so no field coding is required
Powered by two 3-Volt #2032 lithium batteries included

.......more details

Installation Manual

D6375-164

Cable Drum High Lift 164" 1" Bore Torque Force Pair

Maximum hi-lift: 164"
Capacity: 800 lbs per drum
Cable length: Floor to shaft center 181" minus amount of Hi-Lift
Cross reference: DNS 410-164 OMI 164HL M162-4165

PEDALU4272

Aluminum Pedestal Post Dual Height 42" & 72"

Pedestal post with hood
High quality aluminum
42" & 72"
Dual face-plate allows for easy wire connections

Shop drawing

K75-12586

LiftMaster Complete Brake Assembly GH 575V

Complete assembly includes: Brake hub kit Brake release lever Brake disk Spring cup Studs Compression springs Brake solenoid Solenoid cover Spacers Mounting plate Pressure plate Feather key and Fastener.

Installation Manual Manuel d'installation

G71-26438

LiftMaster Timer-to-Close Factory or Field Install

Compatible with models VSL595 BG770 and BG790
Provides an adjustable timer in the operator control circuit which will close the gate automatically after the preset adjustable time interval
May be factory or field installed
Same as 71-26438 G7126438

7001-WG-8-MO

Residential Wood Grain Side & Top W/S Medium Oak 8' Long - Painted Screws to Match

Medium Oak retainer with Medium Oak vinyl
PVC Wrapped
Steel is Notched on Both Ends for Easier Installation
Economical
Dual Fin Vinyl
Painted Screws to Match

.......more details

7001-WG-16-DO

Residential Wood Grain Side & Top W/S Dark Oak 16' Long - Painted Screws to Match

Dark Oak retainer with Dark Oak vinyl
PVC Wrapped
Steel is Notched on Both Ends for Easier Installation
Economical
Dual Fin Vinyl
Painted Screws to Match

.......more details

7001-WG-9-DO

Residential Wood Grain Side & Top W/S Dark Oak 9' Long - Painted Screws to Match

Dark Oak retainer with Dark Oak vinyl
PVC Wrapped
Steel is Notched on Both Ends for Easier Installation
Economical
Dual Fin Vinyl
Painted Screws to Match

.......more details

3BLM-BC

Exterior Control Station 3 Button N4 with Mortise Lockout in Metal Enclose and Best Cylinder

Open-Close-Stop
Dimensions: 7" h x 2-3/4" w x 3-1/2" d
Exterior surface mount

3BLM-BC

6X20SC50

Devanco Loop 6' x 20' Saw-cut 50' lead-in

Manufactured to the highest quality standards to ensure accurate detection our Pre-formed loops come with a 50 foot twisted lead-in ware and available lead-in lengths up to 500 feet.
Ideal for use on existing asphalt or concrete surfaces
Features a non spliced continuous wire throughout loop turns and lead-in.
Requires the use of loop sealer when being installed to ensure long lasting trouble-free detection

Installation Instructions Instructions d'installation Loop Placement Guide Guide de positionnement des boucles

TC134-14

Top Cap 1-3/4" 14 ft Black Box Qty Only ** To extent of Inventory

Sold in box quantities only
12 pieces per box

TC134-12

Top Cap 1-3/4" 12 ft Black Box Qty Only ** To extent of Inventory

Sold in box quantities only
12 pieces per box

TC134-8

Top Cap 1-3/4" 8 ft Black Box Qty Only ** To extent of Inventory

Sold in box quantities only
12 pieces per box

MK-00005

Micanan Hoist Disconnect Switch

lso know as Cut-Out Switch

CB3160500-KOR

Cable 3/16" 7x19 500' Galvanized Supreme

Galvanized cable 3/16" 7x19 500ft spool.
Cable break strength: 4200 lbs
A higher quality cable compared to the Chinese cable
Meets endurance test requirements of over 35000 work cycles
Lubricated for flexability and longer service life

Comparison charts

.295-258-L

Cut-to-Length Torsion Spring .295 x 2-5/8" Left Hand Wound Blue

Priced per inch
For factory installed cones priced seperately - use part no. C-258-INSTALLED

K23-19380-2

LiftMaster Reset Switch Kit for Miracle-One

Reset switch and Harness

29-ABC-15

LiftMaster Fuse 15A

For VSL595 gate operator

1104-ASFT-16FT

Elton Aluminum Stiffener for 1104 16ft

Prevents the 1104 from buckling in the hot sun

EL1-SS

LiftMaster Telephone Entry System Stainless *** No Longer Available

A Telephone Intercom and Access Control System which provides wired telephone intercom communication and secure access control at the gate or door.
Connects directly to the existing residential home phone line so no additional monthly expenses are incurred.
Stainless steel faceplate with black powder coated housing is attractive and tough.
200 (4-digit) unique programmable entry codes provide convenient assigned access.
Optional power supply transformer not included: K002B0821-1

Programming Instructions Instructions de programmation Sell Sheet

LD-11

EMX Base Socket 11-Pin DIN Rail Mountable Black (Was formally Grey)

For use with D-TEK detectors (most commonly used)
Hourglass shaped

17-10336

LiftMaster Pulley 7.000"OD 3/4" Bore 4L-Belt

MAW123-BLK-U

Miller Edge Air-Wave Edge Black Sold per Foot

This pressure sensitive air-wave edge can be adapted to suit a wide variety of applications.
When touch activated the MAW123 sends an immediate pulse of air through the extrusion to an air-wave switch which sends a signal to controls to stop and/or reverse operations.
It has been designed to fit most doors with double track bottom retainers.
With appropriate mounting channel this edge will fit nearly all doors from 11/2" to 2" thick.
The MAW123 is resistant to flame water and most common greases and oils.

4-11-7R

Roller 3" 10-Ball 7" Stem Nylon

Sealed bearing for long life in dusty conditions
7" stem (working length = 6 1/8")

MA117

LiftMaster Counterweight for Arms 15ft & Up

41D605-1

LiftMaster Electric Motor 80kg/100kg

For retail models: WD952KD HD800D and WD952LD

Replacement Instructions Instructions de remplacement

27-20114

Truck Door W-Style Spring Assembly Curbside RHW 35" Long

Wire thickness: .187
Assembled Spring length: 35 inches long
Inside diameter: 2 3/16"
Includes cable drum and bearing assembly winding cone wound onto spring for stronger design and internal spring spacer.

414001

Linear 4-Channel Multi-Code Visor Transmitter 300 MHz

Compatible with 300 MHz Multi-Code receivers
Supplied with visor clip
Easy access to battery and coding switches
Power: 9-volt battery
Codes: 512 codes for each channel (set by dip switches)
RF frequency: 300 MHz

.......more details

Installation Manual

MK00642

Micanan Smart 10.0 Full Feature Circuit Board with Contactor Interface Monitored 575V

For all HP - 575V all voltages 1.5 2 3 & 5HP

Instructions Manual

97-75005

DOT-C2 Reflective Tape 150 ft x 2" W All White

DOT-C2 certified exceeds NHTSA requirements
Highly reflective even up to a 90 degree angle
Quick and easy to apply

97-75004

DOT-C2 Reflective Tape 150 ft x 2" W 11" White x 7" Red Pattern

DOT-C2 certified exceeds NHTSA requirements
Highly reflective even up to a 90 degree angle
Quick and easy to apply

97-75000

DOT-C2 Reflective Tape 24" x 2" W 6" Red x 6" White Pattern

DOT-C2 certified exceeds NHTSA requirements
Highly reflective even up to a 90 degree angle
Quick and easy to apply

PEDALU42-HOOD

Aluminum Hood Only No Post for PEDALU42

Hood only No post
High quality aluminum
Boitier pied estau seulement en aluminum

Shop drawing

GH4416-09-L

Green Hinge #9 12-ga Left Hand *** No longer available

A unique spring-loaded hinge that allows automatic adjustment of the door.
Provides a close tight seal of the door to the building
Green powder coat finish
For doors up to 20ft

M3A

Safety Inertia Brake 1" Bore 2283 Torque PCM3AP

Provides a bearing to support the shaft and prevent the fall of a door if sudden acceleration occurs.
Ideal for commercial and industrial use; specifically with rolling shutters and balanced and well maintained rolling doors.
Fully resettable and reusable after lockout ocurrs.
Commonly paired with commercial safety bottom brackets in sectional door applications.
Fits 1" shaft
Note: Sectional torsion door systems must be well maintained to ensure desired inertia brake activation.

.......more details

M3A Reference Manual M3A Technical Data

GH4416-08-R

Green Hinge #8 12-ga Right Hand *** No longer available

A unique spring-loaded hinge that allows automatic adjustment of the door.
Provides a close tight seal of the door to the building
Green powder coat finish
For doors up to 20ft

GH4416-03-L

Green Hinge #3 12-ga Left Hand *** No longer available

A unique spring-loaded hinge that allows automatic adjustment of the door.
Provides a close tight seal of the door to the building
Green powder coat finish
For doors up to 20ft

GH4416-01-L

Green Hinge #1 12-ga Left Hand *** No longer available

A unique spring-loaded hinge that allows automatic adjustment of the door.
Provides a close tight seal of the door to the building
Green powder coat finish
For doors up to 20ft

LA400DC

LiftMaster Primary Actuator Arm for Single Gate Applications 12VDC New Version

New version has red stripe but will still work on the old LA400

Installation Manual Manuel d'Installation Sell Sheet

12-19504

LiftMaster Flanged Bearing 1" Keyed

H12G09-SS

Hinge #9 x 12 gauge Stainless Steel

Manufactured with 12ga. Rust-Resistant Stainless Steel
Universal Design
Fits Most Overhead Sectional Doors
Priced Per Each

H12G07-SS

Hinge #7 x 12 gauge Stainless Steel

Manufactured with 12ga. Rust-Resistant Stainless Steel
Universal Design
Fits Most Overhead Sectional Doors
Priced Per Each

H12G02-SS

Hinge #2 x 12 gauge Stainless Steel

Manufactured with 12ga. Rust-Resistant Stainless Steel
Universal Design
Fits Most Overhead Sectional Doors
Priced Per Each

Z9967

Roller Chain Puller *** To Extent of Inventory

Allows chain to be pulled together for attachment of the master link
For 35 thru 60 chain

ME120-BLK-E-4FT

Miller Edge 2-Wire Black End Outlet 4 ft Long

Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
Touch sensitive signaling
Temperature range: -30F to 155F
Lead wire: 18 gauge 2ft length
Sensitivity: nominal 4 PSI
2 wire NO configuration

.......more details

Installation Manual Sell Sheet

ME120-BLK-E-5FT

Miller Edge 2-Wire Black End Outlet 5 ft Long

Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
Touch sensitive signaling
Temperature range: -30F to 155F
Lead wire: 18 gauge 2ft length
Sensitivity: nominal 4 PSI
2 wire NO configuration

.......more details

Installation Manual Sell Sheet

MOTOR255-WIRED

Manaras Electric Motor 3/4HP 120/240V 1PH Wired

Electric motor comes pre-wired for a brake
Must specify if operator has electronic circuit board or if it is hard-wired •This item is compatible with BRAKE011

17S

Rolling Steel 2" Flat Stamped Steel Endlock

Endlocks are riveted to curtain slats ends of every other slat to prevent slats from shifting laterally and to prevent curtain wear in guides.
Continuous endlocks are both ends of every slat.
Rivets included with endlocks

8030196

Marantec Belt Connector Kit

Works for all Marantec Belt Drive Openers
For models: Mac Lift M4500M4700Q7500Q7700 M4500e M4700e
Includes two connector pieces and four screws
Not for use on the heavy duty rails used by Q7900 & M4900e

SL316-ZP-COPPER

Zinc Plated Copper Sleeve 3/16" 100 Sleeves per Pkg *price on request

Oval sleeves ONLY
Stops sold separately part # ST316COP. Stops are not zinc plated

5X20SC50

Devanco Loop 5' x 20' saw-cut 50' lead-in

Manufactured to the highest quality standards to ensure accurate detection our Pre-formed loops come with a 50 foot twisted lead-in ware and available lead-in lengths up to 500 feet.
Ideal for use on existing asphalt or concrete surfaces
Features a non spliced continuous wire throughout loop turns and lead-in.
requires the use of loop sealer when being installed to ensure long lasting trouble-free detection
