PED42

Pedestal Post 42" Gooseneck Pad Mount

Black powder coat finish
Faceplate with universal hole pattern to fit almost any access device
2" x 2" square post
Neck is bent with 6 in. center radius giving a tight professional look
Same as G559

MDR/U

Linear 1-Channel MegaCode Universal Plug-In Receiver 318 MHz

Makes any garage door operator compatible with MegaCode transmitters
Simple plug-in design
Easy to install - one connection using two-conductor wire
Memory: storage for up to 10 MegaCode transmitters
Normally open contact activates for 0.5 seconds
Power: 110 VAC +/- 10% 60 Hz

.......more details

02-403P

Push Button Control Station 3-Button Surface Mount NEMA 4/12 O/C/S Green Black Red Part # XALD03H7

Open/Close/Stop allows complete control of the door.
Compatible with all commercial door operators.
NEMA 4 4X 12 13
Outdoor surface mount station with polycarbonate enclosure part # XALD03H7

Sell sheet

PL-SW-PHOTO

Lynx Silent Guard Photocell for Proline Openers

For models built from 2000+
Comes with photoeyes wire and bracket

BL-10

Barlock Kit Complete for 10ft Wide Door Kit includes hardware bag

Kit includes hardware bag and bars (61-1/2")

Assembly Manual

JHDC12S1BE

LiftMaster MAXUM Jackshaft 3/4HP 120/240V 1PH DC Operator 30 Cycles/Hour 1200LB 3" output shaft

New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
Listed to ANSI/CAN/UL325 Standard for USA/Canada
Drive Type 65:1 Gearbox with #50 Chain Output
Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls

.......more details

NINJA-001-BLACK

Rodent Ninja Garage Door Corner Guard Set

Blocks pests from entry
Fills in holes and gaps along garage door frame
Keeps insects mice and unwanted guests outdoors
Kit includes: (1) Right and (1) Left handed Garage Door Corner Guard (6) Self-tapping Screws
Made in the USA

PLA10

NICE Electric Gate Lock Vertical Mount 12V

Required for gates longer than 3m (9.84')
Vertical mounting
Possibility of manual opening
Power: 12V 15VA 50Hz

STRUT-2-1/4-16'

Door Strut 2-1/4" Hemmed 16ft Long

Reinforcement bar 2-1/4"

36645R

Genie Screw Drive Coupler

This coupler only works on the following models manufactured after June 2011.
TriloG 1200 (3064) TriloG 1500 (4064)
PowerMax 1200 (3062) PowerMax 1500 (4062)
GPower 900 (2564)
Powerlift 900 (2562)

37024R

Genie Rail Extension Kit for 8' Doors GBLX-8***No longer available***

Compatible with Quiet Lift 800 DC Belt Drive models.
To be used in addition to a 7' (3-piece) rail to accommodate an 8' high door.

855LM

LiftMaster HomeLink Repeater Kit

This kit contains a repeater and a transmitter
The HomeLink repeater is only compatible with HomeLink equipped vehicles

Programming Instructions

41AB050-2

LiftMaster Electronic Circuit Board Assembly

Assembly includes: Logic board end panel and light sockets
For belt drive models with 2-lights
Also known as 41AB050-2M

22-240

Brake Solenoid 230-240V

Used on all brands of commercial door and gate operators
2 wire connection

6589

WhitingBrush Side Seal assembly for insulated doors

Fits Coldsaver and Tempguard

WRAES

Erone Raduim 2-in-1 AES128 Wireless Receiver 433MHz

The WRAES is a 2-in-1 AES128 encryption receiver.
It works either in stand-alone or connected to an access control system (Wiegand output).
Compatible with any high-security AES128 RADIUM wireless remotes it was designed to prevent remote cloning.
The code sent by the transmitter changes at each activation removing any scanning and copying risk.
A special algorithm ensures a continuous synchronization between the receiver and remotes.
Stand-alone mode: 500 transmitters

.......more details

SW-200

Devanco Torsion Spring Winder 200 for 1-3/4" to 2-5/8" Torsion Springs

pring Winder 200 is a torsion spring tensioning tool designed for use with a cordless drill (Non-impact). Developed for professionals in the installation and maintenance of residential garage doors. The device prevents work-related accidents and significantly reduces physical strain of door installation work. The Spring Winder 200 is suitable for all residential garage door torsion springsranging from 1-3/4 inches to 2-5/8 inches. Technical Specifications:
Weight: 5 kg / 11 lbs
Length: 56 cm / 22 inches
Max. Torque: 147.51 lb/ft
RPM: 500-2000
Material: Aluminium steel plastic

.......more details

Sell Sheet

CAPXS

LiftMaster Smart Video Intercom - S

Designed with small multi-tenant buildings and single family gated homes in mind.
With the myQ Community app residents can see who is at the door before granting/denying access.
Integrated wide-angle camera: Lets you view entrance through a live feed or recorded event.
Integrated BLE radio enabling myQ Mobile Credentials: Ultra-secure encrypted access with the resident’s smartphone.
Cloud-based security: Keeps data protected and safeguards residents’ information. *All LiftMaster Smart Access Solutions (including CAPXLV CAPXLV2 CAPXM CAPXS CAP2D and CAPAC) require monthly subscriptions to a myQ Community plan.

ZAP-8800

Zap 8800 Series-3 Opener

ncludes: (1) 8825-3-(pulley size TBA) c/w motor head assembly and control box

RADIO-RE901

Manaras 1-Channel 24V Dip-Switch (313MHz) & Rolling Code (390MHz) Receiver

For Commercial/Industrial Garage Door Applications
Wall Mount
DIP Switch and Rolling Code Technology
Sixteen (16) Fixed Codes / Receiver
313 MHz Radio Frequency
Controls One (1) Door

.......more details

Programming instructions Manual Sell sheet Manual

FA-NHEX-58-18-J

Lynx Jam Nut 5/8-18 for MCJH

K71-D1PH

LiftMaster Drum Brake Kit 1 Ph 115/230V (Late Model Logic 5 Shoe and Drum Models)

Internal Solenoid Drum Brake with Cable (120V Single Phase) Replacement Kit.
Compatible with LiftMaster® Logic 5.0 Model T SD J H and HJ Industrial-Duty Operators.
Complete service kit includes: Solenoid Cover Brake Solenoid Brake Drum Cable Mounting Plate and Installation Hardware.
Quiet preferred sound profile
Industry benchmark stopping performance with adjustability
Significantly reduced modes of failure

.......more details

Installation manual Manuel d'installation

220315

Allstar Challenger Gear & Sprocket with Bushing

PS241F

Adjustable Regulated Power Supply with Optional BBU 6-24VDC 1AMP

3 preset voltages: 6 12 and 24 VDC
Full adjustment from 2 to 24 VDC if required
Requires AC transformer for input power (minimum 14 VAC for 12 VDC output 26 VAC for 24 VDC output cannot be connected directly to 120 VAC)
Maximum 1 amp. Output at 70 deg. F and free air
Ripple: Minimum load: 0.007vrms Half load: 0.028vrms Maximum load: 0.057vrms
Regulation: 97.5%

.......more details

Wiring Diagram Diagramme de raccordement Spec Sheet Spécifications

D525-54-HL

Cable Drum High Lift 54" D525-54HL Torque Force Pair

Maximum hi-lift: 54"
Capacity: 500 lbs per drum
Max. cable size: 3/16"
Cable length: Floor to shaft center 66" minus amount of Hi-Lift
Cross reference: DNS 54 OMI 54HL M134-1375

FL-KEYPAD

FL-Allstar Wireless Keypad 110927-311 MHz

This wireless keypad controls up to four doors.
Manufacturer's model number: (190-110927)
Dimensions: 6" x 2 3/8" x 1 1/4".

Programming Instructions

OSH-6113-ECB

Manaras Opera-SH 3/4HP 120V 1Ph with Electronic Circuit Board

An ultra high-end heavy-duty V-belt drive industrial jackshaft operator
For use on Standard High and Vertical Lift sectional doors
Can also be used on Rolling doors and Grilles
Comes with a chain hoist for manual operation and a floor level engaging device
Clearence: side room required 16"
25 cycles per day > 100 cycles per day

.......more details

Installation Manual Sell Sheet

973LMC*

LiftMaster 3-btn Security+ Transmitter 390MHz - DISCONTINUED

390 MHz Secruty+ three button visor tranmsitter
Compatible with Security+ systems including Chamberlain Sears Craftsman and Raynor Openers (Safety Signal) manufactured 1997-2005
Visor clip and battery included (part # CR2032)
Same as 973LM 96LM 953CB 956CB
Discontinued 12/31/13 - Replacement options 375LMC 890MAX 893MAX 892LT 894LT

Z9955

Spring Gauge

Ruler style spring gauge
Stainless steel
Confirms spring ID & wire size
Place formed end between 2 coils count 20 coils to obtain wire size

R5110

Bearing 1" Commercial

1" inside diameter 2" outside diameter
1" steel bearing allows the shaft to rotate securely on a garage door assembly
Same as part number 235

BEA-REMOTE

BEA Falcon/LZR Programming Remote

Makes it easy to set up and make adjustments to all key parameters of the Falcon motion detector while at ground level

Programming instructions

DEV-RSFD-7000

Devanco Rolling Steel Fire Door 7000 UL Rated **Made to Order

Model 7000 are manufactured with UL labels of Class A B or C; however their sizes can be customized to an extent with UL oversize certificates.
Model 7000 fire door includes UL labels of 3 1½ and ¾ hours.
The fire door’s heat-sensing technology will allow the doors to close automatically with additional smoke protection available that makes the fire door more reliable than alternative options.
Door sizes can be customized to fit openings that are 43 feet and 6 inches wide by 26 feet tall.
The doors also include viscous-governor technology as well as a 165-degree fusible link.
Pricing varies according to size and options selected.

.......more details

GTO-R4222

Nortek Mighty Mule Photo Beams 12V Pair

For Mighty Mule swing and slide gate openers

Manual

Z9963

Donkey Cone Torsion Spring Winding Tool

Converts a standard 4 hole (90°option) winding cone to an 8 hole (45° option) which is especially helpful in low headroom situations
Donkey Cone is a two-piece coupler that securely attaches to a standard 1-3/4” or 2” cone with two fasteners
Made from 60/61 heavy duty aluminum

380UT

LiftMaster Universal 2-btn Transmitter Gen 5

The Universal Remote Control is compatible with most major brands of garage door openers gate operators and commercial door operators
Operates up to two brands of garage door openers eliminating the need of multiple remotes on your vehicle visor.
Universal compatibility allows you to operate two different garage door manufacturers and/or frequencies at the same time
Security+ 2.0®
Compatible with: LiftMaster® Chamberlain® Craftsman® 390MHz 315MHz 310MHz Security+2.0 390 MHz Security+ Rolling Code 315 MHz Security+ Rolling Code 390 MHz Billion Code 390 MHz Dip Switch (7 8 and 9 position)
Genie® 390 MHz Rolling Code (Intellicode) 315 MHz Rolling Code(Intellicode) 390 MHz Dip Switch (9 and 12 position)

.......more details

380UT Manual (EN/FR)

WD-309961

Wayne Dalton Wired Wall Station 372Mhz 3976

2 Buttons
Color: Cream
Dimensions: 2-1/4"" x 4""
Works with Wayne-Dalton Models: Classic Drive: 3014 3018 3018DLX 3514 3522 3522DLX; Quantum: 3214 3314 3316 3414; Prodrive: 3220C 3221C 3222C 3224C 3320B 3322B 3324B

RADIO-EM144

Manaras 144-Door Transmitter O/C/S 390 MHz

3-button O/C/S transmitter for144 Doors
LED Indicator Nema 1 Enclosure
Soft touch push buttons including a bright red stop button for easy identification
Compatible with Manaras Opera Rolling Code Series "100" Transmitters and receivers
Compatible with Manaras Operators equipped with Board 70 or external receiver Radio-RE901 and Radio-Kit004 & Radio-Kit005
Wall or Post mount

.......more details

Sell sheet

RADIO-RE901A

Manaras 1-Channel 24V Dip-Switch (313MHz) & Rolling Code (390MHz) Receiver with Commercial Antenna

For Commercial/Industrial Garage Door Applications
Wall Mount
DIP Switch and Rolling Code Technology
Sixteen (16) Fixed Codes / Receiver
313 MHz & 390MHz Radio Frequency
Controls One (1) Door

.......more details

Programming instructions

SSSS-1-6FT

Solid Shaft 1" Keyed Stainless Steel 6 ft

303 series Stainless Steel

E/BLOP/246

Automatic Systems Option DBK Fan Heater 120V-400W for BL229

DM11VL-T/FORCE

Cable Drum Vertical Lift 11' D850-132 Pair Torque Force

11' Vertical Lift aluminum die cast alloy.
3/8"-16 x2" hardened cup point set screws installed with red heads.
Color coded: Red=LH and Black=RH. Pair includes (1) LH and (1) RH. Max. Door Height: 11'-1".
Rated Lift per Drum: 425 lbs.
Max. Cable Diameter: 3/16".
Mounting: 1" solid shaft with 1/4" keyway.

.......more details

ALUM-559

Aluminum 24" x 100' Spool Pebble / Kaki # 559

20% thicker than the aluminum sold in retail stores (0.022" )
Gentek # 559
Reverse side is #431 Bright White

Colour chart

C-123-L

Aiphone Door Answering Intercom System

Door answering intercom system for home or business
Master room station: 7-1/2" X 5-1/8" X 1-3/4"
Door station: 4-3/4" X 3-7/16" X 1-1/8"
Power supply 6V DC 800 mA not included

PG-K-R50

Prime Guard Monitored Thru-Beam Photoeye Kit 50 ft Range Relay Output

Prime Guard's rugged housing is suitable for both indoor and outdoor installations.
Dimensions: 5.1" H x 2.8" L x 1.8" W
Weight (Em): 12.2 oz. (Em)
Weight (Rx): 11.2 oz. (Rx)
Aluminum enclosure
Mounting options: Wall floor post

.......more details

Sell sheet

41D7675

LiftMaster Receiver Logic Board 2.0

Also known as: 45ACT

LA500DCS

LiftMaster Secondary 24VDC Actuator Arm for Dual Swing Gate Applications New Model

Includes 40ft cable and junction box

Installation Manual Manuel d'installation Sell Sheet

T501L5

LiftMaster 1/2HP 115/230 Volt 1Ph Commercial Trolley Operator ***NLA

New Logic 5
Suspended from the ceiling the operators are used on sectional overhead doors with standard lift.
T operators are directly attached to drive and control the door.
MyQ® Technology enables you to securely monitor and control your facility operator and lights with your smartphone tablet or computer for greater peace of mind.
Alerts can be received as email or pop-up (push) notifications on a mobile device ensuring the status of your commercial door.
MyQ Mobile App is a free download with no annual activation fee.

.......more details

Installation Manual Manuel d'Installation Sell sheet Brochure

F539.90000

Bircher Infrared Programming Remote RC Duo 2 Red

Conveniently program all parameters from ground level
Backlighting of specific buttons provide instant confirmation of programmed parameter & value
Configure any Hercules 2 Hercules 2s Reflex 2 or UniScan sensor with the same remote
Multiple address feature allows programming of a single sensor even in close proximity to other sensors
Large highly visible buttons
Automatic off feature conserves battery life

.......more details

Programming Instructions F539.90000 Sell Sheet

SOLENOID004

Manaras 575V Brake Solenoid

Same as 22-575
Fits on all 575V garage door or gate operator brake system.

28-32071

Truck Door 2" Horizontal Track with 8" Radius 107" Roadside (LH) for Whiting Roll-Up Doors

SPECS: Length: 107" Fits door sizes: Up to 96" high
Cross Reference: W #11-3
Galvanized steel 14 gauge construction
Tongue and groove for proper alignment at joints
8" radius
For use with 2" diameter steel or nylon rollers

.......more details

DM413

Cable Drum Standard Lift 12' 400-12 Pair

12 ft Standard lift cable drum. Aluminum die cast alloy.
Max. door height: 12'-1".
Rated lift per drum: 375 lbs.
Max. cable diameter: 5/32".
Mounting: 1" tube or solid shaft with 1/4" keyway.
Cross references: D400-144 DNS 4-13 OMI 2100. 3/8"-16 x 2" hardened cup point set screws installed with red heads. Color coded (red=LH black=RH)

.......more details

D-TEK-LM

EMX Industries Plug-in Loop Detector for Liftmaster operators ** To extent of inventory

Plug-in Loop detector for SL575 SL585 SL595 BG770 BG 79024VAC
Works with most LiftMaster gate operators
Won't work with Elite Series Mega Arm Slide & Swing
Simply plug it into the harness already in the operator
Loop lead-in wires connect to operator terminal strip
Gold plated control contacts

.......more details

Installation Manual Sell Sheet

4041-LCN

LCN Door Closer *** repl by 4040-XP

HAE00072

Linear WiFi Wall Station

This Wi-Fi wall station allows direct operation of the door operator and light using the buttons.
When connected to your local wireless access point you can check status get notifications open or close the door and manage user access from any location via the Linear Android or iOS app.
Requirements: To use with the app you will need:
a Wi-Fi network with internet connectivity
a strong Wi-Fi signal in the garage where you are installing the wall station
an Android or iOS smartphone or tablet

.......more details

Programming Instructions

RESET-12A-32V

Doorlec Reset 12A 32V Overload

89493

Marantec RPM Sensor with Wire Harness

For use on M-line/Q-line/EOS models

LMLED1

LiftMaster LED Bulb 60W Equivalent 1/pkg

Designed to minimize radio frequency interference
Daylight white light output (5000K) ideal for garage use
800 lumen / 60w equivalent
22-year life
Durable: shatter-resistant and cold weather tested to -30° F /-34° C

210106

SkyLink Trolley for T-Rails

MK-318-2

Skylink 2-Button Keychain Transmitter

Easy to program.
Remove key fob from the car for enhanced security.
Compact-size 2-button transmitter can operate two garage doors with GB-318C Garage Door Receiver (sold separately).
3V Lithium battery included.
FCC/IC approved.
Works Mastercraft made by Skylink

.......more details

41A5021-1M-315

LiftMaster Receiver Logic Board with Purple Learn Button *** Discontinued

For LiftMaster models: 1345 1346 1355 and 1356
For Chamberlain models: CG40D & CG42D
Replaces Reciever Logic Boards: 41A5021-1H-315 41A5021-4M-315 41A6135-1A 41A6148-1 and 41A6148-1A

27-48-200

Extension Spring 8' Door - 200 lbs Tan - Sold Each

Single - Loop
27" long 48" stretch 200 lb load
Sold individually
Rated for 10000 cycles

Spec Sheet

YSG115-LED

Devanco Stop and Go Light Yellow Housing 115V LED

LED Traffic Light Red/Green Dock Light
Weather-proof 2 piece housing with highest available UV rating
Ultra bright LED's for easy viewing in direct sunlight
Lenses measure nearly 4" in diameter
Requires 4 wall mounting screws 1/4" or 5/16" thread - not supplied
Made in Canada

.......more details

Installation Instructions Instructions d'installation Sell Sheet

D400-144-1

Cable Drum Standard Lift 12' Torque Force Pair

12 ft Standard lift cable drum. Aluminum die cast alloy.
Max. door height: 12'-1".
Rated lift per drum: 375 lbs.
Max. cable diameter: 5/32".
Mounting: 1" tube or solid shaft with 1/4" keyway.
Cross references: DM413 DNS 4-13 OMI 2100.

.......more details

CHAINKEEPER001

Manaras Chain Keeper for Hand Chain

20235R.S

Genie Replacement Keypad Only with Ribbon

Replacement keypad for KEP-1

DTKP

Linear Delta-3 Wireless Keyless Entry 310 MHz

Activates multiple Delta-3 receivers
1-8 digit PIN
Backlit keys for easy viewing
Mounting hardware supplied
Power: 9-volt battery
Codes: 256

.......more details

Programming instructions

41K4629

LiftMaster CPS Interface Black Box (CPICARD)

Allows CPS-U photoeyes to provide a 'NO' contact
Interface is included with CPS & CPS-N4
Also known as 041K4629 1C4489 41K4629 41C4489 CPI

23-10041-1

LiftMaster Double Limit Switch Commercial DP DT

Double limit switch DP DT
For LiftMaster and Micanan operators

110554

Allstar MVP 1-Door O/C/S Receiver 318 MHz ***Replaced by P-831RE

Three channels - three relay outputs
8-wire operator connection
Wire whip antenna with "F" connector
Compatible with Allstar Classic Allister and Pulsar dipswitch transmitters and MVP quik-code transmitters
Power: 24 VAC/VDC
Codes: 19683

.......more details

Programming Instructions

25-10001

Truck Door End Hinge for Todco Roll-Up Doors

Zinc plated steel construction
Four-knuckled to ensure smooth door operation
Cross Reference: T #69035 W #4007 220000

RS-40

Roller Shutter Aluminum Model 40 Made to Order Pricing by Quote Only

The RS-40 is designed for use in window roller shutters door recesses and small shopfronts.
These profiles are of better technical performance and are thus more stable.
At the same time good coil diameters allow to use this profile in small-size boxes.
The foam filling ensures good heat and acoustic insulation.
Its low weight allows the use of manual drives spring- or electric control devices.
The RS-40 profile is available with or without perforation in a wide range of RAL-like colours.

.......more details

MIC001

Manaras Internet Control Device Modification (Op has to be compatible)

The internet control device allows you to control and monitor your garage door from anywhere using the MIC app and your smart device
Includes the MIC device and Wi-Fi compatible board & software
Must be purchased and used with a Manaras monitored operator

CHC-SS-532

Chain Hoist Hand Chain Stainless Steel 5/32" Sold per Foot

Welded chain. Weldless chain is not available in stainless steel

02-103LGO-1

Push Button Station 3-btn Surface Mount O/C/S Nema 1 For LGO Ops only

PBS-3R
Open-Close-Stop
Works with Liftmaster LGO commercial operator
Also known as: 02-103LGO1 02103LGO1
Dimensions: 5-5/16" H x 2-3/8" W x 1-13/16" D
Normally Open contact on Stop therefore it won’t work on any other LiftMaster operator besides the LGO. The 02-103 will work on all operators.

.......more details

STEELCRAFT_PANEL_SEAL

Steelcraft Intermediate Section Seal V-Bead Sold by the Foot

110550

Allstar MVP 3 Channel 24V 3 Terminal 4 Wire Receiver 318 MHz *** NLA

3 channels 4-wire 3-terminal operator connection
Wire antenna included
Compatible with Allstar Classic Allistar and Pulsar dipswitch transmitters and MVP quik-code transmitters
Power: 24 VAC/VDC
Codes: 19683
RF frequency: 318 MHz

.......more details

Programming instructions

CR2025

3V Lithium Button Cell

CSL24UL

LiftMaster New 24VDC Commercial High Traffic DC Slide Gate Operator

Battery Backup: 208 cycles or up to 24 days of standby power when the power is down
Security+2.0®: Access your property quickly with Security+2.0® Technology that utilizes a tri-band signal that virtually eliminates interference and offers extended range each time the remote control is used
MyQ®: Securely control and monitor your Gate Operator from anywhere and get activity notifications through the MyQ® app
Soft start / stop extends operator and hardware life in high-cycle and heavy-gate applications
Wireless dual-gate communication eliminates expensive conduit costs and unsightly driveway scars
Keyed manual disconnect when unlocked allows gate to be operated manually.

.......more details

Installation manual Manuel d'installation Sell sheet

PS243F

Adjustable DC Power Supply 6V/12/24V 3 AMP

3 preset output voltages : 6/12 and 24VDC (an adjustable mode is also available with a jumper setting)
Full adjustment from 2 to 24VDC if required
Maximum 3 amp (Output at 70 deg. F and free air)
Regulation:97.5%
Maximum input voltage 36 volts
Fuse protected

.......more details

Wiring Diagram / Diagramme de raccordement Specifications / Spécifications

60-2728

AB 42GRU-9001 Retro-Reflective Photocell Exterior

Voltage: 12VDC/24VAC/DC
Sensing Distance: 30 Feet
Comes with Bracket and Reflector
NEMA 3 4 4X 6P 12 & 13
Allen Bradley

EX220-1K

Heddolf 1-btn Long Range Transmitter 433 MHz with antenna

1 button gate and garage door opener transmitter
Up to 1500 ft range
10 dip switch format
Includes antenna
Same as ER220-K

Programming Instructions

K22-36899

LiftMaster Single Phase Brake Solenoid L5

4-wire connector for single phase
120 volts on terminals 1 & 2 (closest to the plunger)
240 volts on terminals 3 & 4 (farthest from the plunger)

Wiring diagram

GH105-L5

LiftMaster Gearhead with Brake 1 HP 575V 3-Phase Logic 5

GH-style operators include a floor level chain hoist to ease manual operation in an emergency or power outage.
The operators are typically mounted to the wall when used with sectional overhead doors with vertical or high lift and mounted to the wall or the front of the hood when used with rolling doors and grilles.
GH operators are attached to the door jackshaft to indirectly drive the door.
MyQ® Technology enables you to securely monitor and control your facility operator and lights with your smartphone tablet or computer for greater peace of mind.
Alerts can be received as email or pop-up (push) notifications on a mobile device ensuring the status of your commercial door.
MyQ Mobile App is a free download with no annual activation fee.

.......more details

Installation Manual Manuel d'Installation Sell sheet Brochure

TLS1CARD

LiftMaster Option Board for L4 L5

Works in conjunction with Logic 4 & Logic 5 to provide seven field-selectable modifications
Including six door traffic control options
A means to connect External Open & Close limits by using a selectable DIP switch
Controls both 24V & 110V traffic lights
Formally known as RDGRNCARD

Installation Manual

2598

Aluminum 5/16" Cable Eyelet

For use on Whiting dry freight and refer doors
Use with 1/8" stainless or galvanized cable

50-107-30

Take-Up Reel 3-Wire Metal 30ft Extended

3- wire 18-gauge
Also called Reel Cord

CPS-UN4

LiftMaster Commercial Protector System Thru-Beam Eyes NEMA4

Waterproof photoeyes.
for direct connect to operators with Logic boards. L3 L4 L5
Receiving Eye - A: 50-50997 Sending Eye - A: 50-50998
These eyes will also work on the Micanan UL325 monitored operators

Installation Manual Manuel d'Installation Sell Sheet

TUBE_SHAFT_10FT

Hollow Shaft 1" x 10'-10" Galvanized 16 gauge

When ordering order one foot longer that actual door width

Z9900

Leaf Bumper Spring with bracket Sold as a Pair

Leaf spring with bracket and safety strap.

SG10-24RG-LED

TriLite Stop & Go Traffic Signal 24V LED Yellow Housing

Red and Green LED traffic light
Approx. size: 11-1/2" High x 6-1/2" Wide x 4" Deep
24 volt DC input voltage only
Long lasting low power consumption
A simple reliable and cost-effective way to reduce accidents around the loading dock.
Available in two colors: safety yellow or black.

.......more details

Installation Instructions Instructions d'installation Wiring Diagram Schéma de connexion

NIR

Emx Industries Retro Reflective Photoeye Sensor with Reflector (5200-2)

Watertight packaging
Detection range: 30 feet
6 foot cord
Reflector Bracket and mounting hardware Included
2 LED indicators
Sensitivity adjustment

.......more details

Installation Manual Sell Sheet

VKP1-LM

LiftMaster MyQ Video Keypad

Create unique PIN codes and schedule access for family guests and service providers
Visual Confirmation: Get peace of mind by seeing that loved ones have arrived home safe and sound
Receive real-time notifications and view history of when the garage has been accessed by members of the household
Easy Installation: Enjoy wireless setup with a rechargeable battery and integrated Bluetooth® for fast Wi-Fi® provisioning
Call Button: Unexpected visitors can initiate 2-way audio communication with the myQ account owner to request access
Compatible with LiftMaster Chamberlain Craftsman AccessMaster and Raynor garage door openers made after 1993

.......more details
