T755L5

LiftMaster 3/4 HP 575V 3p Commercial Trolley Operator Logic 5

Low profile trolley operator with brake included

Installation Manual Manuel d'Installation Sell sheet Brochure

743

Fasteners Type AB Sheet Metal Screw 1/4" x 3/4" 1000/Box **** Temp. NLA

7/16" head
Indented hex washer head
Max RPM = 900

7001-16-SANDSTN

Commercial Side & Top Weather-Strip 16' Long - Sandstone (D)

Sandstone galvanized steel with sandstone dual fin vinyl.
Commercial and Residential use.
Steel is notched on both ends for easier installation.
Also known as Taupe
Full case quantity only (10)

BEA-REMOTE

BEA Falcon/LZR Programming Remote

Makes it easy to set up and make adjustments to all key parameters of the Falcon motion detector while at ground level

Programming instructions

26-40001

Truck Door Bottom Seal Standard 98" Long for Todco Roll-Up Doors

Extruded from long lasting rubber
Prevents dirt and moisture from entering cargo bay.
Cross Reference: T #80840 W #3257 610200

HD3115

Commercial Slide Lock for 3" track Long Throw 4" travel

Offset from inside face of door to lockbar: 1/2"
Bright zinc plated steel with spring actuated lock bar.
4" of travel.

210264

Skylink Case Cover Atoms

050ACTBMC

LiftMaster Receiver Logic Board AC WiFi

050ACTBMC is a replacement Bluetooth® Enabled Receiver Logic Board Kit
For use with various LiftMaster® and Chamberlain® Wi-Fi® AC Belt Drive and Chain Drive Garage Door Openers manufactured 2011 to 2022 only.
The unit will feature a yellow learn button
Also known as: 1D8088-1 050ACTWFMC 050ACTWF 1D8808-3 041D80881D8088-1 50ACTWF 050ACTBMC 50ACBL1 50ACBL2 50ACBL3 50ACBL4 50ACBL5 50ACCL1 50ACCL2 50ACCL3 50ACCL4 50ACCL5 50ACBR1 50ACBR2 50ACBR3 50ACBR4 50ACBR5 50ACCR1 50ACCR2 50ACCR3 50ACCR4 50ACCR5

50-CP4

LiftMaster Sensing Probe Free Exit 100ft Lead

Self-contained free exit system designed to detect moving vehicle and open your automatic gate.
Can be installed above or below ground
Connects directly to any gate operator without an external output board.
Works with powered or solar gates.
SPECIFICATIONS: Cable Lead Length: 100 ft.
Power Requirements: 8-24 VAC oe 8-30 CSX

.......more details

GH-343-1.5

Doorlec Industrial Jackshaft Door Operator 1.5 HP 460V 3-Phase

Custom-designed extra heavy-duty industrial-type electric door operator
Worm gear reducer 40:1 ratio
#60 roller chain and sprockets from operator shaft to door shaft.
Door speed: 7 inches per second (approx.)
Adjustable torque limiter
Rotary type limit switches

.......more details

SG-13-NO/NC

Telco Light Curtain with Rectifier w/ Normally Open/Normally Closed Contact 72"

1-10 metre sensing range
16 to 56 parallel scanning beams
Active height of 720 mm to 2520 mm
Length of 868 to 2668 mm
3 different channel placement models
Cable or plug connection

.......more details

8550WLB-485

LiftMaster Belt Drive DC Battery Backup Operator Wi-Fi

12V DC motor with integrated battery Backup
Includes battery 485LM
2-100W lights
Electronic Travel Setting and Auto Force
Built in Alert 2 Close
Incl. Smart Control Panel model 880LM 3-btn remote (893MAX)

.......more details

Installation manual Manuel d'installation Sell sheet Brochure Receiver Logic Board Conversion List

DDO8900W

LiftMaster Light Duty Commercial Dock Door Jackshaft Op.

Ideal for commercial applications that require full vertical lift sectional doors with light-duty cycle requirements
Works with myQ® Business™ Facility to analyze and optimize productivity with intuitive control and monitoring capabilities.
LMi5 Interface monitors up to 5 external sensors enabling the DOCK DOOR SESSIONS feature in myQ business facility and visualization of productivity at the dock.
MyQ® Technology enables monitoring and control of the facility operators through a mobile app.
Built-In Wi-Fi® for simple operator internet connection.
Opens 50% faster in the up direction.

.......more details

Installation manual Manuel d'installation Sell sheet Brochure

MTR3

Linear 3-Channel Visor Transmitter 318MHz ** To extent of Inventory

Activates three MegaCode receivers
Test/operate LED
Visor mounting clip supplied
Visor clip mounts vertical or horizontal
Power: One 2032 battery
Codes: 1000000+ (MegaCode format)

.......more details

Programming instructions Instructions de programmation

SPA-6606-01

Gear Wheel Nylon Sold in Pairs

Dynaco Gear Wheel for Rapid Roll Door
Sold in Pairs

MJ00015

Micanan Brake Shoe Assembly for Old Style Manaras Operators

Assembly includes both right & left brake shoe

DS350

Heavy-Duty Commercial Non-Insulated Rollup Sheet Door with Interior Slide Locks

Heavy-duty Model DS-350 has statewide Florida product approval for wind load protection up to 190 mph.
This door is ideal for commercial applications with openings up to 16’ wide by 16’ high.
Heavy-duty 13-gauge guides attach to 8-gauge wall angles to give maximum wind load protection.
Installation to masonry or steel is quick and simple with no special preparation or overhead tracks needed.
A wide selection of colors to choose from
Made to Order

.......more details

CHK-991

Chain Hoist Keeper

Chain hoist keeper is not the same as the chain keeper

TS150

Wayne Dalton Thermospan 150 Steel Panel

Polyurethane insulation R-Value*=14.16
Max Width 26’2”
1-3/8” Section Thickness
Patented roll-formed integral struts for rigidity
Stucco embossed exterior with pinstriping

JDMG-LG-2030

GDI Jackshaft DC 115V

Brushless DC high reliability high efficiency and low maintenance motor
No maintenance GearMotor sealed stainless steel bearings no limits switches no belts or no hydraulic cylinders to maintain
Soft start soft stop

Sell sheet Technical document

17K

Rolling Steel 2" Flat Continuous Cast Endlock

Endlocks are riveted to curtain slats ends of every other slat to prevent slats from shifting laterally and to prevent curtain wear in guides.
Continuous endlocks are both ends of every slat.
Rivets included with endlocks

YSG12-24LED

Devanco Stop and Go Light Yellow Housing 12-24V LED

LED Traffic Light Red/Green Dock Light
Weather-proof 2 piece housing with highest available UV rating
Wide input voltage range of 10-32V AC/DC eliminates the need to stock 12V and 24V models.
Ultra bright LED's for easy viewing in direct sunlight
Lenses measure nearly 4" in diameter
Requires 4 wall mounting screws 1/4" or 5/16" thread - not supplied

.......more details

Installation Instructions Instructions d'installation Sell Sheet

RPEN4-RFLCTR

LiftMaster Reflector with Support Housing

Replacement reflector for the CPS-RPEN4 photo-eyes

MX00147-NEW

Micanan Complete Clutch Kit for PRO-TB New Style Frame (MX00211)

After January 2006
8" Diameter pulley
Feb 2017 - new part number MX00211

PMT20KIT

Carlo Gavazzi PMT20RI & PMT20I Thru Beam Kit

Suitable for exterior applications NEMA 4
Multi-supply voltage 12-240VDC 24-240VAC
LED indication for power supply and target detected
Not recommended for carwash applications
Operating temperature -25 to +55 C
Terminal 5 Common "NO" on Terminal 4 "NC" on Term. 3

.......more details

Installation Manual

MV00077

Interlock Switch for Sectional Doors

Mounts on the door track to prevent the use of the operator when the door is locked

893LM

LiftMaster 3-btn Transmitter Sec+ 2.0

Controls up to three garage door openers or gate operators or MyQ® enabled light accessories
Equipped with Security+2.0™ rolling code technology that virtually eliminates radio wave interference
3V lithium battery included
Compatible only with Security+2.0™ LiftMaster® garage door openers or gate operators
Equivalent to Chamberlain's 953ESTD

Programming Instructions Instructions de programmation

LSGRY

Loop Sealant Cartridge Grey 29oz

Also available in black (LSBLK)
Can be installed in sub-zero temperatures as long as the surface is clean and dry
Loop sealant gun sold separatley # LSGUN

41A3489

LiftMaster Complete Trolley Assembly for chain drive

For chain drive models 1984 +
Compatible with Sears Chamberlain

Installation Manual

890MAX

LiftMaster 3-btn Mini Transmitter Security+ 2.0

Can be used as a replacement remote control for 80 Series 970 Series and 370 Series LiftMaster remote controls.
Compatible with 315 MHz or 390 MHz garage door openers manufactured after January 1 1993.
For use with gate operators commercial door operators or other products that are 315 MHz or 390 MHz and have a Learn Button.
Includes 3V battery (CR2032)
Same as 953CB

890MAX Manual

17315

Doorlec DC-3200T 32-Channel O/C/S Transmitter 313 MHz

Wall mount transmitter for 32-doors
Includes 9V battery
Old style

Programming instructions

5377.115

Whiting Side Seals 1/2" Track Spacing 115" Long

Most common side seal for Whiting Dry Freight doors.
115 inches will fit almost every size door.

VBELT_4L310

Lynx VBelt 4L 31" (4L310)

Fits the old Lynx 455 garage door opener

MK-00660

Micanan 1 Channel Hand Held Transmitter (for APT applications) Sold Individually

Sold in packs of 10. Priced per transmitter

25-10577

Truck Door Cam Lock Handle Only for Whiting Roll-Up Doors

Steel construction Black E-coat finish.
Cam lock allows one hand operation and easily accomodates padlock or car seal.
Can be used as a lift handle in open position
Back plate is offset to clear bottom seal retainer
Spring assisted handle eliminates door bounce
Handle Keeper Sold Separately. Use part #25-10578

.......more details

ZAP-8800

Zap 8800 Series-3 Opener

ncludes: (1) 8825-3-(pulley size TBA) c/w motor head assembly and control box

S2TR2641E4

Erone 4-Channel Mini Transmitter 433MHz

Open/Close remote for 4 doors
Palm-size transmitters 83 x 48 x 16mm (3.25 x 1.9 x 0.6in)
Ergonomic stylish design rugged & durable
Light grey base with yellow buttons
Unobstructed range: 820 ft (250m)
One 12V lithium battery included

.......more details

Sell Sheet Brochure Wireless System Chart

JHDC-7S-460

LiftMaster MAXUM Jackshaft 1/2HP 460V 3PH DC Operator 30 Cycles/Hour 700LB

New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
Listed to ANSI/CAN/UL325 Standard for USA/Canada
Drive Type 65:1 Gearbox with #50 Chain Output
Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls

.......more details

JHDC_Installation-manual JHDC_Manuel-installation Data sheet Fiche Technique Quick connect guide Guide de connexion rapide Ordering guide Sprocket recommendation

AUXREL

LiftMaster Auxiliary Relay Board MAXUM TDC

For use with various LiftMaster® Logic 4.0/5.0 and MAXUM DC Standard-Duty and Industrial-Duty Commercial Door Operators

Configuration

NINJA-001-BLACK

Rodent Ninja Garage Door Corner Guard Set

Blocks pests from entry
Fills in holes and gaps along garage door frame
Keeps insects mice and unwanted guests outdoors
Kit includes: (1) Right and (1) Left handed Garage Door Corner Guard (6) Self-tapping Screws
Made in the USA

HSLG-411

Linear Commercial Slide Gate Operator 3/4 HP 115V 1 Ph - Heater not Included

Great for industrial and commercial applications
Features the APeX control board
Emergency manual disconnect handle
Powder coat finish
Post mount standard; pad mount optional
Integral entrapment sensing system with dual multi-turn precision potentiometers for accurate adjustment and enhanced safety

.......more details

P-639T

Pulsar 3-btn 9-Door O/C/S Transmitter 318 MHz

Allstar compatible
Wall mount
OPEN-CLOSE-STOP 9 doors
8 dipswitches 318 MHz

Programming instructions

PS-20A

Miller Edge Pneumatic Air Switch in ABS Enclosure

Pneumatic switch offering a reliable low cost alternative to a standard electric sensing adge.
When attached to a hose inserted into the existing weather stripping the PS-20A acts as an effective sensing edge on doors up to 18ft in length.
Applications: rolling doors sectional doors and mass transit.
Electrical configuration: 3-wire SPDT
Temperature range: -20F to 158F
Max pressure: 20 PSI

.......more details

050DCTBF

LiftMaster Receiver Logic Board Kit DC WiFi Bluetooth Enabled

050DCTB is a Bluetooth Enabled Receiver Logic Board Replacement Kit.
For use with various LiftMaster® and Chamberlain® WiFi® DC Chain Drive and Belt Drive Garage Door Openers; powered by myQ®.
The unit will feature a yellow learn button.
Replaces 050DCTWF
Backwards compatible with 050DCTWF
Board: Tri-band Security+ 2.0l

.......more details

HORN015

Manaras White Horn / Strobe Weatherproof Box Includes Rectifier 24VDC

HORN015 is made up of 2 parts - HORN014 & RECTIFIER010

27222A

Genie Sprocket Bushing *** To extent of Inventory

For Genie Chain Drive or Belt Drive Channel Rails.
Fits the following models: PMX700 PMX1200 GPS00-IC GPS1200-IC
Available to extent of inventory

210106

SkyLink Trolley for T-Rails

ALUM-571

Aluminum 24" x 100' Spool Brownstone / Beige Antique # 571

20% thicker than the aluminum sold in retail stores (0.022" )
Gentek # 571
Reverse side is #431 Bright White

Colour chart

MJ5011U

LiftMaster Medium-Duty Jackshaft Op 1/2HP 115V

The MJ door operator is designed for use on vertical lift sectional doors or small rolling doors and grilles.
Maximum recommended duty cycle: 12 cycles per hour
Floor level disconnect
Adjustable friction clutch
Heavy-duty solenoid actuated brake
Easily field converted for right or left mounting

.......more details

Installation manual Sell sheet

60-2439

Allen Bradley Swivel / Tilt Mounting Bracket ***To Extent of Inventory

For 9000 series photo switches

BT501L5

LiftMaster 1/2 HP 115/230V 1p Commercial Trolley Operator with a Brake Logic 5 ***No Longer Available

Low profile trolley operator with brake installed
Comes with #48 roller chain

Installation manual Manuel d'installation Sell sheet Brochure

85870WL

LiftMaster Elite Series 3/4HP AC Chain Drive Wi-Fi Lock Garage Door Opener (8587WL)

MyQ® Technology now with Wi-Fi enables secure monitoring and control of your garage door opener with a smartphone tablet or laptop.
P3™ Motors provide proven reliability and durability.
¾ HP AC Motor Chain Drive System is built to provide maximum power to lift the heaviest doors including carriage house and solid wood.
I-Beam Rail System and reinforced chassis with chain drive provides maximum support.
Security+ 2.0® safeguards garage access – with every click a new code is sent to the garage door opener ensuring the door does not inadvertently open.
Timer-to-Close automatically closes the door after a pre-programmed number of minutes.

.......more details

Receiver Logic Board Conversion List Comparison Chart

JRGX1

Chain Hoist Jack Shaft JRG V2 1" Shaft Torque Force (126689)

Jack Shaft Mounting plastic guide 4.5:1 reduction
Gear drive
Fits 3-3/8" minimum offset
Includes: 26' of galvanized hand chain - doors higher than 15' require additional hand chain
1 chain keeper
2 shaft collars

.......more details

Sell sheet

ULT-MVP

EMX Industries Multi-Voltage Loop Detector (ULT-MVP-U)

Combines small size with 9VDC to 240VAC input range.
Size: 73 x 38 x 78mm
ULTRAMETER™ display indicates the appropriate sensitivity setting the vehicle positioned on the loop
Ten (10) sensitivity adjustments
Four (4) frequency settings
Automatic sensitivity boost (ASB) delay fail-safe/fail-secure and infinite or normal (5 min.) presence

.......more details

Operating Instructions Sell Sheet

MK-00659

Micanan 3 Channel (123) Transmitter 372 MHz

Works with Logic 10.0 receiver

Programming Instructions

20235R.S

Genie Replacement Keypad Only with Ribbon

Replacement keypad for KEP-1

EXTANT

LiftMaster Coax Antenna Connection Kit JF

For use on Medium-Duty commercial operators only

Installation manual Manuel d'installation

83A11-2

LiftMaster Lithium Grease 0.5 oz Tube

Same tube of grease as in the 41C4220A kit
USE PART NUMBER: GREASE same grease larger tube less expensive
Same as K083A0011-1 83A11-2 83A14 83A4 83A8 083A0011-1 083A0011-2 83A11

CPS-RPEN4

LiftMaster Monitored Retro-Reflective Photo Eye with Nema 4 Enclosure for Commercial Door Applications

Installation Manual Manuel d'Installation Sell Sheet

1702LMC

LiftMaster Quick Release Lock

For all vault-type garages
For exterior manual operation
6ft industrial-strength connecting cable
Non-corrosive stainless steel faceplate and spur washer
Extension sleeve for doors up to 2" thick
Positive connection between cable and trolley release

.......more details

1702LMC Manual

K75-18493

LiftMaster Chain Guide Kit

Compatible with SL575 SL585 SL595 SL595U SL595UL and IHSL
Kit includes chain guide retainers and bracket for guide holders

RADIO-EM103SD

Manaras 3-btn transmitter configured as O/C/S 1 door Rolling Code 390 MHz

Open/Close/Stop remote for 1 door
Operates single door: O/C/S configuration
LED indicator CR2032 battery and visor clip included
Field Selectable: Jumper inside the remote can be positioned to Single Door (SD) or Multiple Door (MD)
Compatible with Manaras operators manufactured after August 2013 with control board070E & board070M.

Manual

RADIO-27

Manaras MT-1000 1-btn transmitter 313 MHz ** Replaced by RADIO-EM901 or RADIO-EM903

Open/Close remote for 1 door
Comes with LED battery life indicator
9V battery included
Sunvisor clip included
Alternate part number: MN-100TI-A

Programming Instructions

AK-11

Linear Exterior Digital Keypad (ACP00748)

Self-contained keyless entry system ideal for airports hospitals warehouses office buildings parking lots and many other commercial facilities
Rugged cast aluminum enclosure for indoor or outdoor mounting on a wall or pedestal
Four independent outputs and timers: two form C relays and two solid-state open collector outputs with unique programming per entry code
Up to 480 programmable input codes of one to six digits each for activating either or both relays
Two LED indicators show system status
Key operating features include: door sense input; inhibit input; request-to-exit input; alarm shunt output; timed anti-passback; and keypad lockout

.......more details

Programming Instructions Instructions de programmation

1336.8

Whiting Stainless Steel Roadside Top Closure Bracket for 8" radius

HW-BRG-1

Lynx Bearing 1" x 2" OD

2 in total on a MCJH

OSHW-6112-M-N4-R

Manaras Opera-SH w/Carwash Mod 1/2HP 120V 1Ph Mon ECB w/N4 Photoeyes Right Hand

An ultra high-end heavy-duty V-belt drive industrial jackshaft operator
For use on Standard High and Vertical Lift sectional doors
Can also be used on Rolling doors and Grilles
Comes with a chain hoist for manual operation and a floor level engaging device
Clearence: side room required 16"
Solenoid activated Brake

.......more details

DCWALLCTL

LiftMaster Floor Level Wall Controller with LCD Display

Compatible with LiftMaster MAXUM Commercial Door Operators.
4-line LCD display gives you access to more information at all times
Bringing programming troubleshooting and Diagnostics down to the floor level will save you time and money
Menu based user interface allows you to scroll through edit and save options and settings easily.
Dimensions: 3.586” W x 8.166” H x 1.732” D

LM21AFCB

LiftMaster Advance Fire Control Release Device

UL 864 Revision 9 compliant.
3 count obstruction cycling.
Selectable 10 20 30 or 60-second time delay on alarm.
Test key switch – Floor level testing.
Motor voltage sensing.
Form C relay output.

.......more details

BTM-VB-4

Devanco Bottom Vinyl U-Rubber 4" Black 200' spool

200ft spool of vinyl insert for sectional doors
low temp vinyl
perforations in the bottom to ensure that condensation escapes
Fits most standard bottom retainers

GH-343-2

Doorlec Industrial Jackshaft Door Operator 2 HP 460V 3-Phase

Custom-designed extra heavy-duty industrial-type electric door operator
Worm gear reducer 40:1 ratio
#60 roller chain and sprockets from operator shaft to door shaft.
Door speed: 7 inches per second (approx.)
Adjustable torque limiter
Rotary type limit switches

.......more details

84501

LiftMaster Belt Drive DC LED Wi-Fi Residential Opener

Built-In Wi-Fi® for the easiest way to connect the garage.
Real-Time Alerts indicate the status of the garage door via email or push notifications.
Customized DC Motor is purposefully designed and built to last.
Security+ 2.0® safeguards garage access with every click a new code is sent to the Garage Door Opener ensuring the door does not inadvertently open.
PosiLock® electronically protects against forced openings.
Alert-2-Close signals when a door is being closed by myQ®.

.......more details

84501 Installation-manual 84501 installation-manuel Product guide Guide de produit Receiver Logic Board Conversion List

LDCO863B

Linear DC Powered Garage Door Opener Accepts Both Belt or Chain Rail

Ultra-Smooth and Quiet Industry leading performance with variable speed operation soft start/stop and ultra quiet motor
Integrated Battery Backup Energy-Efficient LED Lighting Long life dimmable LED light panels included. Secure.
Responsive Remote Control Linear MegaCode remote controls operate over long range and employ high-security technology
Release the operator’s quick-disconnect trolley to open or close the garage door manually
Self-Diagnostic System: Confirms proper operation and alerts users both audibly and flashing the lights. In the event of a problem it pinpoints the trouble and alerts users by flashing the courtesy lights
Linear ® Smart App Advanced real-time monitoring and control of garage doors from any mobile device. * Assign custom access and permissions for up to 10 authorized users and schedule door and light operation.*Wi-Fi and internet connection required

.......more details

Remote compatibility chart

LA400PKGUL

LiftMaster Residential 24V DC Swing Gate Operator All-In-One UL325

LED DIAGNOSTIC DISPLAY Simplifies installation and troubleshooting.
WIRELESS DUAL-GATE COMMUNICATION Eliminates expensive conduit costs and unsightly driveway scars.
BI-PART DELAY Monitors and adjusts speed and position of each wing to ensure primary gate closes last.
SYNCHRONIZED CLOSE Simultaneously closes gates. WITH OPTIONAL EXPANSION BOARD
PROGRAMMABLE AUXILIARY RELAYS Easily add additional features such as warning lights/alarms.
ANTI-TAILGATE Prevents unauthorized access. Gate will pause when closing as vehicle pulls onto interrupt loop or breaks photo beam. Once vehicle backs up gate will continue to close.

.......more details

Installation manual Manuel d'installation Data sheet

10RD900

BEA Receiver Module 900 MHz

Long range receiver to allow for wireless activation of any door control.
Provides greater line of sight transmission distance than legacy wireless frequencies along with providing better penetration of obstacles.
Voltage: 12 – 24 VAC / VDC
Operating temperature: -10 to 55C

Product guide

39934S

Genie Res. Wall Mount GDO w/ BBU Smart Pkg 6170H-B

Heavy-duty jackshaft lifting forces is employed with this new design but modified for residential setting and smoother operartion.
The Aladdin Connect smart-garage app comes standard on the 6170H-B logic module
Fast set-up and compatibility with Alexa and Google Assistant devices.
App available on iOS and PlayStore.
Open close get notifications for and set time alerts for your garage from any capable mobile device!
Shows usage reports on up to 20 users. Set pre-determined open close times. No monthly subscription fee!

.......more details

Manual (EN/FR)Sellsheet

WS-BOT-PVC2-09

PVC Bottom L-Retainer and 3" Rubber 9ft Long

Black PVC

LMWEKITU

LiftMaster Wireless Edge Kit Monitored

Meets 2016 UL 325 requirements
Innovative industry leading low-energy Bluetooth® transmission up to 130 ft. range
Integrated Diagnostics with Gate Operator Speed Installation
Protects up to 8 entrapment points
Receiver accepts up to 4 transmitters
Transmitter accepts up to 2 wired resistive edges

.......more details

Installation manual Manuel d'installation Instruction manual Manuel d'instructions Product Guide Guide de produit

F310

Linear GTO Digital Keypad (Wired or Wireless)

As a wired keypad it can operate garage door openers and gate openers that require 24 volts or less and accept normally open contacts.
As a wireless keypad it can be used with any gate or garage door opener that receives a 318 MHz RF signal.
The keypad must be used in conjunction with the GTO garage door receiver kit (part # RB709) on any other garage door.
You may program up to 25 different personal entry codes allowing you to give different entry codes to different users
After entering a valid code pressing any key while the gate is opening will stop the gate; pressing any key while the gate is stopped and the gate will reverse direction.
The keypad will not affect the auto-close setting of your gate opener system.

.......more details

RESET010

Manaras Resettable Overload Fuse 13A 1 Phase

P294-K

Heddolf 4-Wire Single Channel Receiver with F-Connector 318 MHz

Controls one gate or garage door.
318MHz
12 or 24VAC or VDC
9 three position dipswitches (+/0/-) •Switchable relay for pulse to continuous
5 wires: 2 for power 3 for relay contacts
Coax antenna not included. Please see MK-00719 86LM.

.......more details

BL-10

Barlock Kit Complete for 10ft Wide Door Kit includes hardware bag

Kit includes hardware bag and bars (61-1/2")

Assembly Manual

BK021/PR-BOLT

Commercial 3" Safety Bottom Bracket with Bolt Sold as a Pair

Maximum cable diameter: 1/4"
Maximum door weight: 1650 lbs Zinc
Plated Steel
Sold as a pair

Z9207

Sensor Guards Sold as a Pair

Made to fit over garage door sensors
Will fit over most popular sensor brands
Protects sensors from coming out of alignment
Helps protect against water corrosion
Easily installs to the door track or the the wood door frame
Sold by the pair

.......more details

PS241F

Adjustable Regulated Power Supply with Optional BBU 6-24VDC 1AMP

3 preset voltages: 6 12 and 24 VDC
Full adjustment from 2 to 24 VDC if required
Requires AC transformer for input power (minimum 14 VAC for 12 VDC output 26 VAC for 24 VDC output cannot be connected directly to 120 VAC)
Maximum 1 amp. Output at 70 deg. F and free air
Ripple: Minimum load: 0.007vrms Half load: 0.028vrms Maximum load: 0.057vrms
Regulation: 97.5%

.......more details

Wiring Diagram Diagramme de raccordement Spec Sheet Spécifications

90_9210MO

LiftMaster Auxiliary Limit Switch Mod M62 Open Factory Installed

Provides a limit switch for use by others to control auxiliary devices such as lights heaters dock levelers or other equipment.
The switch can be used to turn on or off such equipment when the door is fully opened or fully closed.
When ordering specify whether the auxiliary switch is required on the OPEN or CLOSE side of the control enclosure.
A maximum of 2 switches per operator can be supplied.
Each switch is SPDT (form C) and is rated 10 amps at 125/250 VAC
Wire leads are provided on field install kits

.......more details

MV00021

Swivel Type Pull Cord - SPST Nema 4

Data sheet

JDMG-HOIST

GDI Axial Chain Hoist Kit Nema 4 for JDMG-LG

Can be added in the field

Sell sheet

97799

Marantec Shark Tooth Position Reference Tab Belt Rail (96834)

Same as part number 96834
For belt rail

Replacement Instructions

69C

Skylink 1-Button Universal Keychain Remote *** NLA

It's small enough to carry in your pocket or purse
The 69C is a great universal remote and it is compatible with almost any garage door up to 2007 (see compatibility chart for exact brand names).
It has just one simple button and a unique keychain attachment which makes it ideal for use with convertibles motorcycles bicycles or any other vehicle without the usual sun visor.
It connects to your garage door using a series of DIP switches making it simple to program it even if your garage door dates as far back as the 1980s.
Model 69c is not compatible with Stanley "Securecode"
Compatible frequency: 390/318/315/310 Mhz

.......more details

Compatibility Chart

AMB-3001

Ambassador 3001 1-Button Transmitter ***Replaced by DR & DT

Open/Close remote for 1 door
Can be substituted with Allstar at 311 MHz however change the #9 dip switch to negative.

VBELT_5L345

Doorlec VBelt 5L 34.5" *** Replaced by VBELT_5L350

Same as part number #19052

7140251

FAAC Hydraulic Oil HP2 1 Litre *** To extent of Inventory

CH501L5-RH

LiftMaster Hoist Op. with Carwash Mod. 1/2 HP 115/230 VAC Logic 5 Right Hand

Industrial Duty Hoist Operator with Damp Environment modification.
Comes with CPS-UN4 photoeyes

Installation Manual Manuel d'Installation Sell sheet Brochure

22-575

Brake Solenoid 575V

Same as Solenoid004
Fits on all 575V garage door or gate operator brake system.

41A6408

LiftMaster Travel Module (8500 3800P 3800PLD & 3900) - 41B8861

Works on model 8500

Programming Instructions Instructions de programmation

HOMELINK-REPTR

LiftMaster HomeLink Repeater Kit ** same as 855LM

All 2006 or older vehicles require a repeater kit installation
In 2007 and newer if the HomeLink does not program with opener install a repeater
The remote supplied in the repeater kit must be kept for future programming and is NOT to be used as a garage door opener remote
